Husqvarna 135 X-TORQ [19/35] Page g 135 135e

Page G 135, 135e CARBURETOR & AIR FILTER

Position Article Quantity Notes Kit

1 504 72 47-01 1 Insulation wall assy

2 504 72 45-01 1 Insulation wall rubber 1

3 504 72 44-01 1 Inulation wall plastic 1

4 504 20 12-01 1 Inlet pipe

5 503 20 02-16 4 Screw

6 506 45 05-01 1 Carburettor

544 28 44-01 1 Throttle rod assy

544 97 64-01 1 Filter holder assy

544 39 26-01 1 Shackle

504 71 25-01 1 Guide sliding shoe

544 84 43-02 1 Control assy

544 97 66-01 1 Screw

13 503 20 02-40 3 Screw

14 544 80 54-02 1 Air ﬁlter assy (44 micron)

14 544 80 54-03 1 Air ﬁlter assy (felt)

503 93 66-01 1 Air purge

16 544 40 19-01 1 Hose, airpurge suction
