Husqvarna 135 X-TORQ [25/35] Page k 135 135e

Page K 135, 135e CRANKCASE

Position Article Quantity Notes Kit

1 544 93 25-03 1 Crankcase assy

2 503 87 58-02 1 Stiffening plate 1

3 503 87 54-02 1 Bar bolt 1

4 537 33 46-01 1 Bar bolt 1

5 544 03 64-01 1 Bar bolt 1

6 503 24 09-05 1 Needle roller 1

7 530 02 61-19 1 Check valve 1

8 537 40 35-01 1 Filter 1

9 544 08 33-01 1 Oil screen 1

10 544 33 16-01 3 Guide pin 1

11 503 86 93-01 1 Support

12 544 11 12-01 1 Tank cap assy

13 537 21 50-01 1 Sealing 12

14 503 57 89-01 1 Holder 12

15 503 88 63-01 1 Chain catcher pin

16 503 21 88-76 2 Screw

17 501 00 76-01 1 Lateral support

18 503 21 51-03 1 Screw

19 544 28 46-01 1 Chain guide plate

20 503 21 70-10 1 Screw

21 544 28 65-01 1 Spike inner

22 503 21 75-20 2 Screw

23 544 25 15-01 1 Hand guard

24 503 89 24-01 1 Catch

25 503 89 30-01 2 Screw

26 503 43 65-01 1 Lock spring
