English | 11
u Always start drilling at low speed and with the bit tip
in contact with the workpiece. At higher speeds, the bit
is likely to bend if allowed to rotate freely without contact-
ing the workpiece, resulting in personal injury.
u Apply pressure only in direct line with the bit and do
not apply excessive pressure.Bits can bend causing
breakage or loss of control, resulting in personal injury.
Additional safety warnings
u Switch the power tool off immediately if the applica-
tion tool becomes blocked. Be prepared for high
torque reactions which cause kickback. The applica-
tion tool becomes blocked when it becomes jammed in
the workpiece or when the power tool becomes over-
loaded.
u Hold the power tool securely. When tightening and
loosening screws be prepared for temporarily high torque
reactions.
u Secure the workpiece. A workpiece clamped with
clamping devices or in a vice is held more secure than by
hand.
u Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility com-
pany for assistance. Contact with electric lines can lead
to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age or may cause an electric shock.
u Always wait until the power tool has come to a com-
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is intended for impact drilling in brick, con-
crete and stone, as well as for drilling in wood, metal,
ceramic and plastic. Tools with electronic control and right/
left rotation are also suitable for screwdriving and thread
cutting.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Keyed chuck
(2)
"Drilling/impact drilling" selector switch
(3)
Lock-on button for on/off switch
(4)
On/off switch
(5)
Rotational direction switch
(6)
Auxiliary handle (insulated gripping surface)
(7)
Depth stop
(8)
Handle (insulated gripping surface)
(9)
Chuck key
(10)
Screwdriver bit
a)
(11)
Universal bit holder
a)
a)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Impact drill GSB 570
Article number
3601AB70..
Rated power input W 570
Power output W 300
No-load speed min
-1
0–3000
Impact rate at no-load speed min
-1
0–48  000
Rated torque Nm 1.4
Clockwise/anticlockwise ro-
tation
●
Spindle collar diameter mm 43
Max. drilling diameter
– Concrete mm 13
– Masonry mm 13
– Steel mm 10
– Wood mm 25
Chuck capacity mm 1.5–13
Weight according to
EPTA-Procedure 01:2014
kg 1.7
Protection class
/II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/vibration information
Noise emission values determined according to
EN62841-2-1.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 94dB(A); sound power level
105dB(A). Uncertainty K=5dB.
Wear hearing protection!
Bosch Power Tools 1 609 92A 6FC | (09.02.2021)
