saw using the ON/OFF switch (7) and wait
until the table saw cools down. Then press the
overload switch (8) and restart the table saw.
3. ASSEMBLY INSTRUCTIONS
Assembly of the table extensions
Fig. F
•
Assemble table extensions (2pcs) like shown
on Fig.F1
•
Tighten the screws (4pcs) like shown on Fig.F2
•
Use knobs (4pcs) to tighten the table
extensions Fig.F3
Assembly of the dust extraction
Fig. I
•
Assemble dust extraction like shown on Fig.I
•
Attach vacuum cleaner to A (Fig.I)
Installation of the machine on a workbench or
on the subframe
This machine is a stationary machine and for
safety reasons must always be firmly installed and
not used for mobile applications.
You can install the machine in two ways:
a.
As a stationary machine on a workbench. In
this case the machine must be secured to the
workbench with 4 bolts.
b.
As a stationary machine on the subframe. In
this case the machine must be secured to
the subframe with 4 bolts and the subframe
anchored to the floor or to a floor plate with
dimensions of at least 1 square metre
Assembly of the bench saw on the workbench
Fig. B & C
Before adjusting the saw, make sure the
plug is removed from the socket.
Fig. B shows the distance of the holes to be
drilled in the workbench on which to fasten the
machine. Drill holes of 8 mm.
Only use the machine after it has been
assembled completely and it has been
screwed onto the workbench or the
frame.
•
Fig. C shows the part to be sawn out (310 x
310 mm), so that the sawdust can fall through
it and piling up is prevented! Only if you do not
use an extraction system!
•
Fasten the machine with bolts.
•
If the frame is used it must be fixed to the floor
with at least 2 screws on the front legs (Fig.H)
Assemble undercarriage
Fig. G
1. Create the square by using beams from D
using bolts and nuts supplied (type 1) , make
sure beams D1 (2pcs) are placed over D2 (Fig.
G1, and Fig.G2) do not tighten the bolts yet
2. Mount beams B on the machine using bolts
type 2, make sure they are mounted on the
sides of the table extensions (Fig.G3)
3. Mount legs A on the machine like on Fig.G4
and use 2 bolts (type 1) per leg to tighten
4. Mount the square in between the legs, make
sure the D2 beams are on the side of the table
extensions
5. Make sure the square is fixed well, and tighten
the nuts and bolts well (Fig.G5)
6. Place rubber feet (Fig.G6)
7. Tighten the nuts and bolts from step 1
8. Mount 2 sliding feet (Fig.G7)
Assembly and attachment of the parallel guide
Fig. D
•
Attach the aluminium guide (A) to the
positioning block (B).
•
Now you can attach the complete parallel
guide to the bench top.
•
Slide the parallel guide via one end of the
positioning rail (C) over the bench top.
•
Adjust the position of the aluminium guide
profile (A) such that the end corresponds to the
rear edge of the saw.
Assembly of the riving knife and the protective cap
Fig. E
•
Turn sawblade completely upwards (Fig.A,
number 5)
•
Assemble the guard (Fig.E1 & Fig.E2)
•
Mount the guard by pushing the button on the
guard. Then lower it onto the riving knife, as
shown on figure E. Release the button. The
guard is secured if you hear a clicking noise.
Attention: the upper saw blade guard must be
able to move freely.
