34 | English

1 609 92A 4RG | (15.11.2018) Bosch Power Tools

To measure, briefly press the measuring button (2) [ ]. The measured value will be

shown at the bottom of the display.

11.430 m

10.160 m

8.890

0.0°

m7.620

Repeat the above steps for each subsequent measurement. The last

measured value is at the bottom of the display, the penultimate meas-

ured value is above it, and so on.

Continuous measurement

In continuous measurement mode, the measuring tool can be moved relative to the tar-

get, during which the measured value will be updated approx. every half a second. You

can, for example, move a desired distance away from a wall while reading off the current

distance at all times.

Select the continuous measurement mode .

To switch on the laser beam, briefly press the measuring button (2) [ ].

Move the measuring tool until the desired distance is shown at the bottom of the display.

11.623 m

-64°

Briefly pressing the measuring button (2) [ ] will interrupt the continu-

ous measurement. The current measured value will be shown at the bot-

tom of the display. Pressing the measuring button (2) [ ] once more

will start the continuous measurement again.

Continuous measurement automatically switches off after fiveminutes.

Area measurement

Select the area measurement mode .

Then measure the width and length one after the other as with a length measurement.

The laser beam remains switched on between the two measurements. The distance to be

measured flashes in the indicator for area measurement .

19.355 m

0.0°

5.080 m

3.810 m

The first measured value is shown at the top of the display.

After the second measurement has been completed, the area will be

automatically calculated and displayed. The end result is shown at the

bottom of the display, while the individual measured values are shown

above it.

Volume measurement

Select the volume measurement mode .
