Instruction manual
5
FM radio
Maintenance and care
Switch off the unit, unplug from the power
supply. The outside of the appliance can be
cleaned with a slightly damp cloth.
Accessories
Turn on the device.
Press the MODE button repeatedly to
select the FM mode.
• Press and hold Play/Pause to
automatically scan and save all
available radio stations. The procedure
will take several minutes and cannot be
interrupted.
• Once the search is finished, you can
•
•
press the ⏮ or ⏭ button to
go to a previous or a next saved
station. Rotate the volume knob to
adjust volume.
1 pc
1 pc
Audio system
USB Type C cable
Wired microphone
Carrying strap
Instruction manual
1 pc
1 pc
Specifications
Nominal power consumption 5 W
FM radio 87.5 - 108 MHz
Battery power supply Li-ion, 3.7V, 3000 mAh
Net weight 1.85 kg
Unit dimensions 368(L) * 135(W) * 195(H) mm
Output power 45 W
*The built-in battery life is approximate, depending on the conditions and nature of use (number of recharge
cycles of the built-in battery, environmental conditions, use of lighting effects, sound volume level, playback
source, type of content being played).
Specifications and functions are subject to change without notice. It is connected with continuous
improvement of the device.
MANUFACTURED AND DISTRIBUTED BY TECHNO ELECTRIC LIMITED,
Legal address: 801 Luk Yu Building, 24 - 26 Stanley Street, Central, China
RGB Light
Press the button repeatedly to switch
among three RGB light modes or switch it
off.
1 pc
Microphone
• You can connect the microphone for
karaoke or other purposes into this unit by
connecting it to the 6.35mm microphone
input jack. Please do not plug the
microphone when the unit is charging.
• While connected, you can
control the microphone volume by
rotating the MIC knob, and echo effect
by pressing the corresponding
ECHO-/+ buttons on the top panel.
• Press the REC/DEL button
to enable recording with the microphone.
During the recording, the echo effect
should be set to the minimum. Press and
hold REC/DEL to delete the recorded file.
USB adapter (not included):
Voltage input: AC 220V/50-60Hz
Voltage output: 5V ⎓ ≥1.0А
Music playtime up to 10 hours*
