PCDVRR470GPS
© Prestigio Plaza Limited
11
EN General Information
Specifications
Display: 3", IPS,
640×360,
Touch sсreen
. Sensor: 1
/2
.
8
"
,
Sony Starvis 335
(
5
MP). Viewing angle: 140°. Diaphragm: 1.
9
. Video resolution:
WQHD 2.5К 2560
×1440
at 60 fps. Maximum frame rate: 60 fps Recording mode: cyclic (1/3/5 min). Video codec: H.265
. Digital video recording format: TS. Photo resolution:
5 MP. Number of lenses: 6. Number of IR filters: 1. Internal memory: 16 MB. Supports memory cards: microSD (SDHC/SDXC) up to 128 GB
. Processor:
NTK96670. GPS module: built-
in. Warm start: no more than 1 minute. Cold start: no more than 5 minutes. CPL filter: removable. Video camera
database: yes. Wi-Fi: IEEE 802.11 b/g/n (2.4 GHz). Wi-Fi module emission power: 13~17 dBm. Wi-Fi power consumption: 190
mW (standby mode),
650 mW (operating mode). Motion sensor: yes. Night scene mode: Yes. Electronic image stabilization: no. G-sensor: yes. Speaker: built-
in. Microphone:
built-in. Power supply: car power adapter (input: 12–24 V (DC), output: 5 V / 2.0 A (2.4 A for Apple devices)
(DC); 2 connectors). Supercapacitor
(non-removable): 2×2.7 V, 3.3 F. Supercapacitor lifespan: 1 MM cycles, or 30,000 h. Overvoltage protection: yes. Operating conditions:
temperature
−20...+70 °C, relative humidity 15–65% (without condensation). Storage conditions: temperature −30...+80 °C, relative humidity 15–65%.
Colour: black.
Body material: ABS plastic + tempered glass. Mounting type: magnetic holder on suction cup. Si
ze (L×W×H): 9
5
×56.
7
×
35
mm. Weight: 11
1.7
g
Functions
Compact device
PCDVRR470GPS
combines the functions of video recorder and GPS
-
informer with a database of coordinates of the main points of
road
control. GPS-receiver determines the coordinates of the ne
arest control point and, according to the current database, displays information about
the permitted speed and additional types of control. The device is also equipped with a Wi
-
Fi module for connection to a mobile device
Scope of supply
Video recorder
PC
DVRR470GPS
with built
-
in GPS
-
module, a magnetic suction cup holder with a USB Type
-
C connector, car power adapter
(2 output connectors USB Type-A), cable USB Type-C (cable length 3.6 m), CPL filter, accessories for cable installation, card reader, cloth fo
r screen
cleaning, textile case, quick start guide, warranty card
Warranty
2
year
s
Service life
2
year
s
Operating instructions
Memory card installation
While observing the correct orientation of the microSD card (not included), insert it into the video recorder with the external power turned off. Press until you hear a click.
Video recorder installation
1. Choose a place to mount the video recorder.
2. Insert the magnetic suction-cup holder into the mounting slot.
3. Remove the protective film from the sticky surface of the suction cup holder.
4. Loosen the mechanism holding the suction cup. Install the suction cup and clamp the mechanism.
5. Connect the car charger cable (included) to the USB Type-C power connector of the video recorder.
6. Connect the charger to a vehicle power source (cigarette lighter socket in the car).
To permanently place the video recorder in one place, use the 3M tape mount.
Video recorder operation
When you start the engine of the car, the video recorder will automatically start cyclic recording of video files of 1/3/5 min duration (the duration is set by the user
in the settings of the device). At the same time, the status LED indicator of the device will turn blue When the engine turns off, the video recorder will save the last
video file and stop working. Also, if you press the power button for a long time, it is possible to turn on/off the video recorder manually (with external power on).
