PCDVRR480W

© Prestigio Plaza Limited

Note. The device's microSD card stores videos of the selected duration, sorted by date. When the memory on the card runs out, the device automatically deletes

the oldest video file and then records a new one.

3. Make the changes and activate them by pressing .

4. Press > to return to video recording. The recording will continue automatically.

Locking a video file from being overwritten or deleted

To block the current video file from being overwritten or deleted, press in Record mode. The lock indicator will appear in the upper right corner of the screen.

If the acceleration sensor (G-sensor) is triggered, the blocking will be done automatically.

Video files viewing

You can view video recordings on the PCDVRR480W device itself (with external power on).

It is also possible to view on a PC with codecs installed to play TS format files encoded in H.265. To do this, remove the memory card from the video recorder and

connect it to a PC using the memory card reader (included).

Connecting the device to the app

2. Save the file to the microSD card using the memory card reader (included).

Note. It is recommended to use a formatted microSD card.

3. With the video recorder powered off, insert the microSD card in the direction shown on the device's body until you hear it click into place.

The firmware update will start automatically once power is supplied to the device and the microSDcard is initialized.

WARNING! The update process may take some time. Do not unplug the device from the power source or turn off the vehicle's ignition until the update process is

complete.
