Soundmax SM-CSL693 [3/16] Mounting the speakers

To prevent short circuit never put or leave any metal objects (e.g. coins or metal tools) inside the

acoustic system.

Make absolutely sure that the speaker terminals are connected to the proper outputs from the sound

source.

Never run the wiring on the outside of the vehicle or under it where it can be damaged by road hazards or

the moving parts of the vehicle. Use existing wire channels, sills, panels and molding strips inside the vehicle

to hide the wiring for safety and a neat appliance.

Make sure the wire of the negative pole terminal is disconnected from accumulator while connecting the

speaker terminals. Turn on the various components and increase the volume slowly. Remember to check and

re-check all connections to insure proper installation and use.

Do not continuously use the speaker system beyond its nominal power handling capacity.

Keep recorded tapes, watches, and personal credit cards using magnetic coding away from the speaker

system to protect them from damage caused by the magnets in the speakers.

If you cannot find the appropriate mounting location, consult your car dealer or your nearest service

center before mounting.

CAUTION: Take extreme caution when working near the gas tank, gas lines, brake or hydraulic lines and

electrical wiring.

Mounting the speakers

Installation kits are available from your car dealer or local stereo shop to help make your installation easy.

These kits also give your installation a clean, customized appearance. For questions about installations

methods please consult a professional auto sound dealer/installer.

Choose the place of installation for acoustic system. For most acoustic system designated regular places

in the automobile will fit. In this case you need to know only the assembly depth. Before installing the system

check its assembly depth first.

If you chose a non-standard arrangement of speakers at which it is necessary to cut them in panels of the

automobile, use a mould (not included). For perfect arrangement of the system closely follow the mold

geometry, as it is very important for correct installation of your system (А=151 mm, В=220 mm, ØС=5 mm).
