Hisense U5120GW+ [19/24] Bluetooth operation
![Hisense U5120GW+ [19/24] Bluetooth operation](/views2/2017205/page19/bg13.png)
19
DRC Setting: Press the button 12 times
in succession, the display shows: Dts Drc
Heavy / Dts Drc Mid / Dts Drc Min.
or
Adjust the Dialog Control: Press the
button 13 times in succession, the display
shows: Dts Dialog Control 0~6.
4. Select the content with VOL +/- buttons on
the remote control, and then press
to
conrm your selection and exit the settings.
- Repeating these steps will toggle the feature
ON and OFF.
9. OPTICAL / COAXIAL / HDMI /
ARC Operation
1 Ensure that the unit is connected to the TV or
audio device.
2 Press the
(SOURCE) repeatedly on the
unit or on the remote control to select the
OPTICAL, COAXIAL, HDMI 1, HDMI 2, HDMI
ARC mode.
3 Operate your audio device directly for
playback features.
4 Press the VOL +/– button to adjust the
volume to your desired level.
Tip:
• The unit may not be able to decode all digital
audio formats from the input source. In this
case, the unit will mute. This is NOT a defect.
Ensure that the audio setting of the input
source (e.g. TV, game console, DVD player, etc.)
is set to PCM or Dolby Digital (Refer to the
user manual of the input source device for its
audio setting details) with HDMI IN 1 / HDMI 2
/ HDMI ARC / OPTICAL / COAXIAL input.
• When selecting a dierent audio format, the
unit will display the following as follows:
Audio (abbreviation) Display
LPCM 2ch PCM AUDIO
LPCM 5.1ch PCM AUDIO
LPCM 7.1ch PCM AUDIO
Dolby Digital DOLBY AUDIO
Dolby TrueHD DOLBY AUDIO
Dolby Digital Plus DOLBY AUDIO
Dolby Atmos -
Dolby TrueHD
DOLBY ATMOS
Dolby Atmos -
Dolby Digital Plus
DOLBY ATMOS
DTS DTS
DTS Discrete Surround DTS
DTS-ES 6.1 Matrix DTS
DTS-ES 6.1 Discrete DTS
DTS 96/24 DTS
DTS 96/24 ES Matrix DTS
DTS Express DTS
DTS-ES 8-Channel Discrete DTS
DTS-HD High Resolution DTS-HD
DTS-HD Master Audio DTS-HD
DTS:X DTS:X
DTS:X Master Audio DTS:X
10. Bluetooth Operation
10.1 Pair Bluetooth-enabled Devices
The rst time you connect your bluetooth device to
this player, you need to pair your device to this player.
Note:
- The operational range between this player
and a Bluetooth device is approximately 26
feet (8m) (without any object between the
Bluetooth device and the unit).
- Before you connect a Bluetooth device to this
unit, ensure you know the device’s capabilities.
- Compatibility with all Bluetooth devices is
not guaranteed.
- Any obstacle between this unit and a Bluetooth
device can reduce the operational range.
- If the signal strength is weak, your Bluetooth
receiver may disconnect, but it will re-enter
pairing mode automatically.
1 During ON mode, press the
button
repeatedly on the unit or the
button on
the remote control to select Bluetooth mode.
“NO BT” will show on the display if the unit is
not paired to any Bluetooth device.
2 Activate your Bluetooth device and select
the search mode. “Hisense U5120GW+” will
appear on your Bluetooth device list.
- If you cannot nd the unit, press and hold
the
button to be searchable. The display
will show “BT Pairing” and you will hear
"Pairing" from the unit.
3 Select “Hisense U5120GW+” in the pairing
list. After successful pairing, you will hear
"Paired" from the unit, and the display panel
shows “BT_IN”.
