If unit fails to operate properly

Carefully read the instruction to make sure the unit is being operated properly. Check the following before you

take your unit to the local dealer for repair.

Symptom Possible cause Solution

No sound The volume control regulator set in the

minimal position

Adjust sound level

Bad power connections Check to see that all the power and speaker

leads are securely connected

The audio cassette receiver is damaged Take your unit to the local dealer for repair

Unnatural

sound

Acoustic system cables are connected

without observance of polarity (+ or -)

Check to see that all the power and speaker

leads are securely connected

Damage speaker wire or speaker Replace the speaker or speaker wires

The audio cassette receiver is damaged Take your unit to the local dealer for repair

Note: Good ground connections eliminate most electrical noise problems and require tight contact with the

metal vehicle chassis. Remove plastics, paint or rust for good electrical contact.

Specification

Loudspeaker сone

woofer: 16х24 cm (6x9”) injection cone

midrange: 3 cm (1.2”) PEI dome

Magnet

main: ferrite 20 Oz magnet

midrange: neodymium

Peak output power

280 W

Rated output power

140 W

Impedance 4 Оhm

Sensitivity 94 dB

Frequency response

30-20000 Hz

Dimensions

263.5 x 184 x 102.2 mm

Net / Gross weight

1.9 kg / 2.307 kg

Gift box dimension (L x H x W) 275 mm х 110 mm х 390 mm
