Dreame Cordless Stick Vacuum P10 White [31/43] Installation

WallMountInstallationDiagram

The mount should be installed in a cool, dry place near a power outlet. Make sure the

installation area is clear of any pipes such as gas or water lines, and air ducts, electric wires

and cables, or drainage lines.

ConnectingtheChargingAdaptertotheWallMount

1. Rotate the clip in the bottom of wall mount 90 degrees counterclockwise to remove it

from the mount.

2. Insert the charging adapter cord into the notch on the clip.

3. Rotate the clip 90 degrees clockwise until it clicks into place.

1. Before installation, measure the wall in the height of 100 cm above the ground.

2. Mark and drill two 8 mm diameter holes into the wall with an electric drill. Insert the wall

plugs into the holes.

3. Align the position holes on the mount with the holes on the wall. Fasten it to the wall

with the included screws.

Installation

100 cm
