Dear customer, Thank you for choosing Thermex water heater. Our company wishes you comfort-
able use of our products!
Before using the electric storage water heater for the first time, we recommend you
read this manual carefully and follow its recommendations.
Pay attention to the importance of correctly filling out the warranty card by the trading organization!
The warranty period commences on the date of purchase of the water heater.
Examine the appearance of the product in the presence of the representative of the seller for
detection of mechanical damage (dents, scratches, etc.). Mechanical defects found at home cannot
be considered as warranty!
Do not install or switch on the product in fire-hazardous areas with aggressive, acidic media.
Do not connect the water heater to a network that is not connected to ground!
Especially important items are marked with the «Warning!»
This manual covers Thermex water heaters Model N 10 O, N 15 O, N 10 U, N 15 U. The full name of
the model of the water heater you purchased is indicated on the nameplate on the water heater case.
Standard delivery
Water heater with RCD (optional)............. 1 pcs.
Safety valve............................................. 1 pcs.
Anchor fasteners ..................................... 2 pcs.
Operation manual .................................... 1 pcs.
Packaging................................................1 pcs.
Intended use
The water heater (hereinafter EWH) is designed to provide hot water to household and industrial
facilities having a cold water supply main with the required parameters specified in the table «Main
technical specifications».
The EWH should be operated in closed heated rooms and is not intended for continuous flow
operation.
14
Description Fig. 1
EWH case
Hot water outlet (with the red ring)
Cold water outlet (with the blue ring)
Drain valve
Safety valve
Safety valve handle
Safety valve drain pipe
Drainage to the sewage system
Flow pipe
1.
2.
3.
4.
5.
6.
7.
8.
9.
Valve of cold water supply to EWH
Valve of hot water outlet
Cold water main pipe
Hot water main pipe
Hot water shutoff valve
Cold water shutoff valve
Cover
Temperature control knob
Indicator lamp
10.
11.
12.
13.
14.
15.
16.
17.
18.
The manufacturer reserves the right to change the design and characteristics of the water heater
without prior notice.
Information on the place of application and the method of determining the date of
manufacture:
The release date of the product is encoded in a unique serial number located on the nameplate (label)
at the bottom of the product case. The serial number of the product consists of thirteen digits. The third
and fourth digit of the serial number is the year of manufacture, the fifth, sixth is the month of
manufacture, the seventh, and eighth is the day of the manufacture of the EWH.
Safety precautions
1. All installation, plumbing and electrical work must be carried out by qualified personnel
only!
2. Electrical safety and anti-corrosion protection of the EWH are guaranteed only if there is an
effective grounding performed in accordance with the current Electrical Installation Code (EIC).
3. When installing and operating the EWH, the following is prohibited:
to connect the power supply if the EWH is not filled with water;
џ
to remove the cover when the power is on;
џ
to use the EWH without grounding or use water pipes for grounding;
џ
to connect the EWH to water supply system with a pressure of more than 0.7 MPa. If the pressure in
џ
the water main exceeds 0.7 MPa, or is not stable and periodically exceeds 0.7 MPa, then at the inlet
Main technical specifications
10
15
16 min
28 min
0,56
0,69
204,4
251,8
Volume,
(l)
Average heating time
0
at ∆Т=45 С
(2 kW)
Daily constant loss,
(kW/24 h)
Actual annual electricity consumption*,
(kW/h)
(* for daily constant loss)
±5°С
Accuracy of temperature maintenance in storage mode
0.05 / 0.7 MPa
230 V~, 50 Hz
2000 W
G1/2
IPX4
+3...+40°С
+18…+74°С
Cold water supply pressure, min/max
Single-phase power supply network, voltage, frequency
Tubular heater capacity
Diameter of the threads of the cold and hot water nipples
International Protection Marking
Operation at ambient temperature
Adjustment range of water heating temperature
15
EN EN
