English 27

How to remove carbon filter:

1. Remove aluminum filters.

2. Turn the carbon filter to the left and pull it.

3. Replace the old carbon filter with the new one.

4. Put the filter back into place.

If necessary, clean the outside of the air cleaner with a soft, damp cloth. Do not use

any abrasive cleaning agents. For painted stainless steel surfaces: to avoid scratching it is

recommended to wipe them with a soft, damp cloth in the painting direction. Do not remove the

lamp cover during the surface cleaning process.

Caution! Do not use the steam generators for cleaning.

Caution! Not following the above rules for cleaning the appliance and replacing filters may

cause fire.

Caution! If you need to transport the air cleaner, first of all, disconnect it from the power

supply and proceed with disassembly. It is recommended that you transport it in the original

packaging. If this packaging is not available, package the appliance using materials that

prevent possible damage resulting from transportation.

Replacing lamps

Before replacing lamps, remove the hood’s power cable. Lift

the front glass up and remove the aluminum cartridge filter.

Then:

- Disconnect the socket and lamp connector by pulling

back on the plastic tab as shown in the figure on the left to

open the locking device.

- Hold the lamp by the body and turn the 2 fixing tabs on

the lamp clockwise or counterclockwise to fit into the gaps on

the lighting panel. After the fixing tabs line up with the gaps,

hold the lamp by the body and remove it.
