SPECIFICATIONS
Camera
Image Sensor
1/2.8" CMOS
Signal System PAL/NTSC
Min. Illumination
Color: 0.002Lux@ (F1.6, AGC ON), B/W: 0Lux with IR
Shutter Time 1s to 1/100,000s
Day & Night
Dual IR Cut Filter with Auto Switch
Wide Dynamic Range 120dB
Angle Adjustment
Bracket, pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type Fixed
Focus
2.8mm/4mm
Lens Mount M12
Aperture
F1.6, Fixed
FOV
Horizontal field of view: 99.7° (2.8mm)/83.3° （4mm）; Vertical field of view: 55.1°(2.8mm)/46.8°(4mm)
Illuminator
IR LEDs
2
IR Range Up to 50 m
Wavelength
850nm
White LEDs/Warmlights N/A
Compression Standard
Video Compression
S+265/H.265/H.264
Video Bit Rate 32 Kbps~6 Mbps
Audio Compression
G.711/G.711U/ADPCM
Audio Bit Rate 8K~48Kbps
Max. Resolution
1920 1080
Main Stream
PAL: 25fps (1920
1080, 1280 720, 704 576, 640 480)
NTSC: 30fps (1920 1080,1280 720, 704 480, 640 480)
Sub Stream
PAL: 25fps (704
576, 704 288, 640 360, 352 288)
NTSC: 30fps (704 480, 704 240, 640 360, 352 240)
Third Stream N/A
Image Setting
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement BLC/3D DNR/HLC
ROI
Support 8 fixed regions of coding
OSD 16 16, 32 32, 48 48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions
Picture Overlay
N/A
Privacy Mask Yes, 4 regions
Smart Defog
Yes
