First 5053-3 [6/74] English
![First 5053-3 [6/74] English](/views2/2027871/page6/bg6.png)
4
ENGLISH
Tip: If you set the timer to half the preparation time,
you hear the timer buzzer when you have to shake
the ingredients. However, this means that you have
to set the timer again to the remaining preparation
time after shaking.
7. When you hear the timer buzzer, the set
preparation time has elapsed. Pull the pot out of
the appliance
Note: You can also switch off the appliance
manually. To do this, set the time to 1.
8. Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide
the pot back into the appliance and set the
timer to a few extra minutes.
9. To remove ingredients (e.g. fries), pull the pot
out of the Hot-air fryer and place it on trial
framework, and press the basket release button
and lift the basket out of the pan.
Do not turn the basket upside down with the
pot still attached to it, as any excess oil that
has collected on the bottom of the pot will leak
onto the ingredients.
The pot and the ingredients are hot. Depending
on the type of the ingredients in the air fryer,
steam may escape from the pot.
10. Empty the basket into a bowl or onto a plate.
11. When a batch of ingredients is ready, the Hot-air
fryer is instantly ready for preparing another
batch.
CONTROL PANEL INSTRUCTIONS
Button A power button
Button B
preset button
Button C
time/temperature control
button “decrease”
Button D
time/temperature control
button “increase”
Button E
temperature control button
Button F
timer control button
Light G
fan indicator light
Light H
temperature light
Light I
timer light
Light J
temperature indicator light
Light K
timer indicator light
Light L
recipe indicator light
OPERATION INSTRUCTIONS:
Power Key (A)
Once the Basket and pot are properly placed in the
main housing, the Power light will be illuminated.
Selecting the power key for 3 seconds will make the
unit default temperature 200°C, while the cooking
time will be set to 15 minutes. Selecting the Power
key a second time will start the cooking process.
Pressing the power key for 3 seconds to close the
entire device during cooking. All the lights go out,
the fan stops working.
Note: During cooking, you can touch the keys to
control the pause and start of cooking.
Preset Key (B)
Selecting the Preset key enables you to scroll
through the 8 popular food choices. Once selected,
the predetermined time and cooking temperature
function begins.
Temperature Control Key (E)
Selecting the Temperature Control Key, the Keys
C+D enable you to increase or decrease cooking
temperature 5°C at a time. Keeping the Key
held down will rapidly change the temperature.
Temperature Control range: 80-200°C.
Timer Control Key (F)
Selecting the Timer Control Key, the Keys C+D
enable you to increase or decrease cooking time,
one minute at a time. Keeping the key held down
will rapidly change the time
SETTINGS
This table below will help you to select the basic
settings for the ingredients.
Note: Keep in mind that these settings are
indications. As ingredients differ in origin, size,
shape as well as brand, we cannot guarantee the
best setting for your ingredients.
Because the Rapid Air technology instantly reheats
the air inside the appliance instantly
Pull the pot briefly out of the appliance during hot
air frying barely disturbs the process.
Tips
• Smaller ingredients usually require a slightly
shorter preparation time than larger ingredients.
• A larger amount of ingredients only requires
a slightly longer preparation time, a smaller
amount of ingredients only requires a slightly
shorter preparation time.
