Jimmy BX7 Pro Blue Anti-mite Vacuum Cleaner [5/64] Dust cup cleaning

Use of the Product

Insert the power cord into the machine and plug into the socket. Press on/off button,the

machine is in vacuuming+UV+tapping mode and all indicators light up. Press the mode button

to switch the machine to tapping+vacuuming mode. Press the mode button again to switch

the machine to UV+vacuuming mode. Press the mode button again to switch back to the

UV+tapping+vacuuming mode. Press on/off button again, the machine stop working(The LED

display area has the dust sensor function. When in clean state, the dust concentration light

turns blue. When in dirty state, the dust concentration light turns red. As the dust concentration

decreases, the dust concentration light slowly changes from red to blue.)

Note:

1.When the LED display shows brush trapped mode and the icon ash, please clean the lter and brushroll in

time.

2.For safety reasons, the UV light only works within 3cm above object as well as less than 30 inclination

degrees. Otherwise, the UV light will automatically turn off.

3.Do not touch the air outlet on the bottom of the machine in case of hand scald.

LED Display

Cleaning and Maintenance

Note:

1.Filters are available at dealers.

2.It is recommended to clean the dust cup after each

use. When the filter is blocked due to excessive dust

accumulation, it needs to be cleaned and replaced if

necessary.

Dust Cup Cleaning

1.Turn off the machine and unplug the power

cord. Then press the release button and lift

upward. (Figure 1)

Vacuum Mode

Brush trapped Mode

(When the dust is full

or brush trapped, the

icon ashes.)

(Indicate dust

concentration change)

UV Mode

Tap Mode

Dust concentration light

Release button
