BM series 17
5.2. Storing Active Units
The units and modes can be selected and stored in the function table.
The sequence of displaying them can be arranged to fit the frequency of use.
The units stored are maintained in non-volatile memory, even if the AC adapter is removed.
1 Press and hold the RANGE key until ba5fnc of
the function table is displayed in the weighing mode,
then release the key.
2 Press the RANGE key several times to display Unit .
3 Press the PRINT key to enter the unit selection mode.
4 Specify a unit or mode in the order to be displayed
using the following keys.
RANGE key
.........
To display the units sequentially.
RE-ZERO key
......
To specify a unit or mode.
The indicator appears when
the displayed unit or mode is specified.
Examples
Unit Display
Gram g
Milligram mg
Counting mode PC
Percent mode %
Density mode DS
5 Press the PRINT key to store the units or modes.
The balance displays end and then displays the next
menu item of the function table.
6 Press the CAL key to exit the function table.
Then the balance returns to the weighing mode with the
selected unit.
Specify the uni
t
Press and hold
Press
s
everal time
s
The indicato
r
is
displayed at the
units specified.
Store them
Selection ke
y
Example
s
