Soundmax SM-DVBT270 [5/36] Connection

Connection

Antenna input

• Connect an external DVB-T/T2 antenna

(cable) connector to the antenna input RF IN.

The signal in the block cable antenna

can fail to contain DVB-T/T2 signal due to the

carrier frequency altered by the cable network

operator.

In order to receive digital air TV signal

use an indoor or outdoor UHF antenna. Specify

the possibility and quality of digital air signal

with your local digital TV service providers. The

absence of a stable TV signal in your area can-

not be a reason for returns or refunds without

an additional test of TV signal reception in your

area.

To increase the reception quality of

the state digital air television in rural areas or at

significant distances from a broadcasting

center we recommend using individual active

outdoor UHF antenna with a high resistance

factor, and placing them at maximum possible

heights.

Power adaptor input

• Connect the DC power adaptor to this

input and plug it into the electrical outlet.

HDMI-out

• If your TV has an HDMI video input,

connect it to an HDMI output of this unit using

an HDMI cable (included).

Composite AV output

• Connect the AV output to the

composite AV input on your TV using a mini

RCA cable.
