5
ENGLISH
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.
ITS COMMERCIAL USAGE AND USAGE IN PRODUCTION
AREAS AND WORK SPACES IS PROHIBITED.
ASSEMBLING THE VACUUM CLEANER
After unit transportation or storage at low tempera-
ture keep it for at least three hours at room tempera-
ture before switching on.
– Unpack the unit completely and remove any stickers
that can prevent unit operation.
– Check the unit for damages; do not use it in case of
damages.
– Before switching the unit on, make sure that your
home mains voltage corresponds to the unit operat-
ing voltage.
• The unit is intended for operation from an AC power
network with the frequency of 50 or 60 Hz. The unit
does not need any additional settings for operating
with the required rated frequency.
Note: before replacing the brush (1) or the nozzles (27, 28)
or cleaning the dust box (12) switch the vacuum cleaner off
and extract the power plug from the mains socket.
Attaching and removing the flexible hose
• Insert the flexible hose ending (8) into the air inlet (10)
(fig. 1).
• Keep pushing the hose through, applying limited
force, until the locks trigger.
• If you need to remove the flexible hose, carefully pull it
and detach the hose.
Attaching the telescopic pipe
and the attachments
• Attach the telescopic extension pipe (4) to the noz-
zle (5).
• Extend the lower part of the telescopic pipe as neces-
sary (fig. 2).
• Select the necessary attachment – floor/carpet brush
(1), crevice nozzle (28), or the furniture brush (27) –
and attach it to the telescopic pipe (4) (fig. 2).
• If necessary, attach the attachments (28, 27) directly
to the ending (5).
• Keep your hands on the pipe (4) or the nozzle (5)
while in use.
USING THE VACUUM CLEANER
Floor/carpet CoolClean brush (1)
Set the switch (2) on the brush (1) to the required position
(depending on the type of the surface being cleaned).
2-in-1 crevice nozzle (28)
The crevice nozzle is intended for cleaning of radiators,
crevices, corners and between cushion spaces.
The nozzle can be used as a dust removing brush or a
crevice nozzle (for cleaning of radiators, crevices, corners
and between cushion spaces). To select an operation
mode, set the nozzle to the correct position.
Furniture brush (27)
Use the furniture brush (27) to clean the soft fabrics of
furniture upholstering.
Dust bin (12)
The dust box (12) is equipped with the filter (23), which
filters out the garbage and dust from incoming air.
Note:
– the nozzles (27, 28) are stored in special compart-
ments inside the vacuum cleaner body. To access
them, open the front cover of the vacuum cleaner (7)
and remove them
– always keep the filter (23) clean - the overall perfor-
mance of the vacuum cleaner depends on it;
– the dust box (12) is equipped with the protector
(12), preventing installation of the dust box with no
filter (23). Always check whether the filter (23) has
been installed correctly before reinstalling the dust
box (12).
Safety measures
• Do not use the vacuum cleaner near hot surfaces,
such as ashtrays and in places where inflammable
liquids are stored.
• Take sharp objects away from the floor before clean-
ing to prevent unit damage.
• If the suction power of the vacuum cleaner decreases
rapidly while cleaning, switch it off immediately and
check the telescopic pipe (4) and the flexible hose (6)
for obstruction. Switch the vacuum cleaner off, then
unplug it, remove the obstruction and only after that
continue cleaning.
OPERATION
ATTENTION! Only switch the vacuum cleaner on with
the dust box (12) equipped with the filter (23), as well as
the outlet filter (25) installed. Always check whether the
filters (23, 25) have been installed correctly.
• Before using the unit, unwind the power cord to the
required length and insert the power plug into the
mains socket.
• The yellow mark on the power cord indicates the
maximum cord length. Do not unwind the power cord
further than the red mark.
• To switch the vacuum cleaner on, press the on/off
button (14).
• You can adjust the suction power during operation, by
turning the adjustment switch (17). The airflow can be
adjusted with the switch (3).
• Once you have finished cleaning, press the on/off
button (14) and extract the power cord plug (14) from
the mains socket.
• The power cable winding button (16) is located on the
body of the vacuum cleaner. To wind up the power
cable, press the winding button (16). Hold down the
cable with your hand as it winds up to keep it from
lashing and to avoid damage.
• The brush (1) can be kept in the brush storage (18)
between usages.
CLEANING AND CARE
Cleaning the dust bin (12)
Remove garbage and dust from the dust bin (12) after
every room cleaning.
– Switch the vacuum cleaner off and unplug it.
– Press the button (13) and carefully lift up the front
cover (7) (fig. 3). Take the handle (11) and extract the
dust box (12) from the vacuum cleaner body by pull-
ing it (fig. 3).
– Position the dust box (12) above the garbage bin.
– Press the locking button (19) and open the dust box
cover (20) (fig. 3).
