32 | USER MANUAL

Rear camera

With the help of rear camera you can get a high-resolution image behind your car for safe parking or

recording while driving. Modern double recording technology allows saving recordings both in front

and behind the car for xing any unforeseen situation.

Rear camera installation

There are two options of using rear camera.

Option 1. DVR camera for getting view behind the car. Install the camera on the rear window with a

sticker, put the wire through the cabin, connect the wire to the rear camera port.

Option 2. Combination of DVR camera and rear camera for back view when parking. Install the camera

on the rear window inside the car. In this case, it is required to apply +12 V when driving backwards.

This will allow the device to automatically switch the image from the front to the rear camera in the

parking mode.

Note: It is strongly recommended that works on installing the camera and connecting +12 V should

be done by qualied personnel with the necessary skills. Cable routing may require special tools or

attachments. Make sure these works are safe.

The camera is not waterproof.

1. Video cable port

NAVITEL s.r.o. hereby declares that the device NAVITEL R9 DUAL is compatible with the European directive RED 2014/53/EU.

The full text of Declaration of conformity is available at the following internet address:

www.navitel.cz/en/declaration_of_conformity/r9dual
