PA_JBL_Boombox 3 Wi-Fi_QSG_Global_DV2_V3
FR
EL
DA
ES
DE
FI
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
HU IT NL
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
NO PL TP-BR
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
SV
ZH-CN
JP
ar
TR
ZH-TW
KO
he
RU
ID
MM
MM
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
TEKNISKE SPECIFIKATIONER
Transducer: 52 mm x 90 mm woofer, 20 mm tweeter
Rated output power: 30 W RMS for woofer, 10 W RMS for tweeter
Frequency response: 60 Hz - 20 kHz
Signal-to-noise ratio: > 80 dB
Battery type: Li-ion polymer 27 Wh (equivalent to
3.6 V/ 7500 mAh)
Battery charge time: 4 hours (5 V / 3 A)
Music play time: up to 20 hours (dependent on volume level
and audio content)
USB port: Type C
USB rating: 5 V / 2 A (maximum)
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz (2.4GHz ISM Band, USA 11
Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725
- 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz &
5.47-5.725GHz <20dBm, 5.725-5.825GHz
<14dBm (EIRP)
Product dimensions (W x H x D): 482.4 x 256.9 x 199.7 mm / 19.0 x 10.1 x 7.9
Net weight: 6.7 kg / 14.7 lbs
Packaging dimensions (W x H x D): 565 x 324 x 256.5 mm / 22.2 x 12.8 x 10.1
Gross weight: 9.74 kg / 21.47 lbs
Maximum operation temperature: 45 °C
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
WHATS IN THE BOX
* Power cord quantity and
plug type vary by regions.
POWER ON
APP
Download the JBL One app
and connect Boombox 3 Wi-Fi
to your Wi-Fi network.
MUSIC STREAMING
Stream music through the
JBL One app or the services
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
PLAY
On the speaker, press
to
select the playlist and speaker
you have enabled in the JBL
One app.
WORK WITH SMART
HOME
(Sold separately)
Complete setup in the Google
Home or Amazon Alexa app.
BLUETOOTH PAIRING
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
PLAY
On the speaker, press
to
select the playlist and speaker
settings that you have preset
in the JBL One app.
CHARGING
RESET SPEAKER
WATERPROOF
DUSTPROOF IP67
To protect battery lifespan, fully charge at least once every 3 months.
Battery life will vary due to usage patterns and environmental
conditions.
Do not expose the JBL Boombox 3 Wi-Fi to liquids without removing
cable connection. Do not expose JBL Boombox 3 Wi-Fi to water
while charging. It may result in permanent damage to the speaker
or power source.
Chemicals, salt or foreign particles in your pool or the ocean can
damage the waterproof seals or harm the connector surface over time
if not rinsed o after use. After a liquid spill or rinse, do not charge your
speaker until its completely dry and clean. Charging when wet might
damage your speaker.
FR
Pour protéger la vie de la batterie, chargez-la complètement au moins une
fois tous les 3 mois. La durée de vie de la batterie varie en fonction des modes
d’utilisation et des conditions environnementales.
N’exposez pas la JBL Boombox 3 Wi-Fi aux liquides sans débrancher son câble.
N’exposez pas la JBL Boombox 3 Wi-Fi à leau pendant sa charge. Lenceinte ou la
source dalimentation pourraient être endommagées dénitivement.
Les produits chimiques, le sel ou les «corps étrangers» de votre piscine ou de
locéan peuvent endommager les joints détanchéité ou la surface du connecteur
au l du temps sils ne sont pas rincés après utilisation. Après le déversement
d’un liquide ou un rinçage, ne chargez pas votre enceinte tant quelle nest pas
complètement sèche et propre. Charger votre enceinte lorsquelle est mouillée
peut lendommager.
DA For at beskytte batteriets levetid skal du oplade fuldt ud mindst en gang
3 måned. Batteriets levetid varierer på grund af brugsmønstre og miljøforhold.
Udsæt ikke JBL Boombox 3 Wi-Fi for væsker uden at erne kabelforbindelsen.
Udsæt ikke JBL Boombox 3 Wi-Fi for vand under opladning. Det kan medføre
permanent beskadigelse af højttaleren eller strømkilden.
Kemikalier, salt eller fremmede partikler i din pool eller i havet kan beskadige
de vandtætte tætninger eller skade overade-forbindelserne over tid, hvis de
ikke skylles af efter brug. Efter væskespild eller skylning må du ikke oplade
din højttaler, før den er helt tør og ren. Højttaleren kan tage skade, hvis den
oplades, mens den er våd.
ES Para proteger la duración de la batería, cárgala completamente al menos una
vez cada 3meses. La duración de la batería depende de los patrones de uso y las
condiciones ambientales.
No expongas el JBL Boombox 3 Wi-Fi a líquidos sin quitar la conexión por cable.
No expongas el JBL Boombox 3 Wi-Fi al agua mientras se carga. Puede provocar
daños permanentes en el altavoz o en la fuente de alimentación.
Los productos químicos, la sal y partículas ajenas presentes en las piscinas o en el
mar pueden dañar los sellados a prueba de agua o la supercie del conector con el
tiempo si no se enjuagan después del uso. Si se moja a causa de algún derrame de
líquido o lo has enjuagado, no cargues el altavoz hasta que esté completamente
limpio y seco. Si cargas el altavoz mientras está húmedo, se puede dañar.
TR Pil ömrünü uzatmak için en az 3 ayda bir tam olarak şarj edin. Pil ömrü kullanım
şekline ve çevresel şartlara bağlı olarak değişiklik gösterebilir.
Kablo bağlantısını çıkarmadan JBL Boombox 3 Wi-Fi’ü sıvıya maruz bırakmayın.
JBL Boombox 3 Wi-Fi’ü şarj ederken suya maruz bırakmayın. Hoparlöre veya güç
kaynağına kalıcı olarak hasar verebilir.
Havuzunuzdaki veya okyanustaki kimyasallar, tuz veya “yabancı parçacıklar” su
geçirmez contalara zarar verebilir ya da kullanımdan sonra durulanmazlarsa
zamanla konektör yüzeyi zarar görebilir. Sıvı döküldükten veya durulandıktan
sonra, tamamen kuruyana ve temizlenene kadar hoparlörünüzü şarj etmeyin.
Islakken şarj etmek hoparlörünüze zarar verebilir.
ﻒﻠﺘﺨﻳﻭ .ﺮﻬﺷﺃ 3 ﻞﻛ ﻞﻗﻷﺍ ﲆﻋ
ً
ﺓﺪﺣﺍﻭ
ً
ﺮﻣ ﻞﻣﺎﻜﻟﺎﺑ ﺎﻬﻨﺤﺷﺍ ،ﺔﻳﺭﺎﻄﺒﻟﺍ ﺮﻤﻋ ﺔﻳﺤﻟ AR
.ﺔﻴﺌﻴﺒﻟﺍ ﻑﻭﺮﻈﻟﺍﻭ ﻡﺍﺪﺨﺘﺳﻻﺍ ﻁﺎﺃ ﺐﺒﺴﺑ ﺔﻳﺭﺎﻄﺒﻟﺍ ﺮﻤﻋ
.ﻞﻴﺻﻮﺘﻟﺍ ﻞﺒﻛ ﺔﻟﺍﺯ ﻭﺩ ﻞﺋﺍﻮﺴﻠﻟ JBL Boombox 3 Wi-Fi ﺾﻳﺮﻌﺗ ﺐﻨﺠﺗ
ﻚﻟﺫ ﻦﻋ ﺞﺘﻨﻳ ﺪﻘﻓ .ﻦﺤﺸﻟﺍ ﺀﺎﻨﺛﺃ ﺀﻠﻟ JBL Boombox 3 Wi-Fi ﺾﻳﺮﻌﺗ ﺐﻨﺠﺗﻭ
.ﺔﻗﺎﻄﻟﺍ ﺭﺪﺼﻣ ﻭﺃ ﺕﻮﺼﻟﺍ ﱪﻜ ﻢﺋﺍﺩ ﺭﴐ
ﺔﺣﺎﺒﺴﻟﺍ ﻡﺣ ﺓﺩﻮﺟﻮﳌﺍ “ﺔﺒﻳﺮﻐﻟﺍ ﺕﺎﺌﻳﺰﺠﻟﺍ” ﻭﺃ ﺢﻠﳌﺍ ﻭﺃ ﺔﻴﺋﺎﻴﻤﻴﻜﻟﺍ ﺩﺍﻮﻤﻠﻟ ﻦﻜ
ﺭﻭ ﻞﺻﻮﳌﺍ ﺢﻄﺳ ﻒﻠﺘﺗ ﻭﺃ ﺀﻠﻟ ﺔﻣﻭﺎﻘﳌﺍ ﺕﺍﺩﺍﺪﺴﻟﺍ ﻒﻠﺘﺗ ﻥﺃ ﻂﻴﺤﳌﺍ ﻭﺃ
ﻭﺃ ﻞﺋﺍﻮﺴﻟﺍ ﺏﺎﻜﺴﻧﻻ ﺔﻋﺴﻟﺍ ﺖﺿ
ّ
ﺮﻌﺗ ﺍﺫﺇﻭ .ﻡﺍﺪﺨﺘﺳﻻﺍ ﺪﻌﺑ ﻪﻔﻄﺷ ﻢﺘﻳ ﺍﺫﺇ
ﺔﻋﺴﻟﺍ ﻦﺤﺷ ﻱﺩﺆﻳ ﺪﻘﻓ .
ً
ﻣﺎ ﺎﻬﻔﻴﻈﻨﺗﻭ ﺎﻬﻓﺎﻔﺟ ﺪﻌﺑ ﻻﺇ ﺎﻬﻨﺤﺷ ﺐﻨﺠﺗ ،ﺎﻬﺑ ﺮﻤﻐﻟﺍ
.ﺎﻬﻔﻠﺗ ﱃﺇ ﺔﻠﺘﺒﳌﺍ
PL Aby zachować czas eksploatacji akumulatora, należy go ładować co najmniej
raz na trzy miesiące. Żywotność akumulatora zależy od sposobu jego użycia i
warunków otoczenia.
Nie narażać urządzenia JBL Boombox 3 Wi-Fi na kontakt z cieczami
bez wcześniejszego odłączenia przewodu. Nie narażać urządzenia JBL
Boombox 3 Wi-Fi na kontakt z wodą podczas ładowania. Mogłoby to skutkować
trwałym uszkodzeniem głośnika lub źródła zasilania.
Środki chemiczne, sól lub inne „ciała obce“ w basenie lub zbiorniku wodnym
mogą z czasem uszkodzić wodoodporne uszczelniania lub powierzchnię
złącza, jeśli nie zostaną spłukane po użyciu. Po rozlaniu lub spłukaniu cieczy,
nie ładuj głośnika do jego całkowitego wyschnięcia i oczyszczenia. Ładowania
wilgotnego głośnika może spowodować jego uszkodzenie.
KO 배터리 수명을 보호하려면 3개월에 이상 배터리를
완전히 충전하십시오. 배터리 수명은 사용 패턴 환경
조건에 따라 다를 있습니다.
연결된 케이블을 분리하기 전에 JBL Boombox 3 Wi-Fi 액체에
노출하지 마십시오. 충전 중에는 JBL Boombox 3 Wi-Fi 물에
노출시키지 마십시오. 그러지 않으면 스피커 또는 전원이
영구적으로 손상될 있습니다.
수영장이나 바다에있는 화학 물질, 염분 또는 “이물질”은 사용
헹구지 않으면 시간이 지남에 따라 방수 씰을 손상 시키거나
커넥터 표면을 손상시킬 있습니다. 액체를 쏟거나 스피커를
헹군 경우 완전히 마르고 깨끗한 상태가 되기 전까지 충전하지
마십시오. 젖은 상태에서 충전하면 스피커가 손상됩니다.
IT Per preservare la durata della batteria, eettuare una carica completa almeno
una volta ogni 3 mesi. La durata della batteria varia a seconda del tipo di
utilizzo e delle condizioni ambientali.
Non far entrare in contatto JBL Boombox 3 Wi-Fi con i liquidi senza aver rimosso
il collegamento del cavo. Non far entrare in contatto JBL Boombox 3 Wi-Fi con
l’acqua durante la ricarica. Si potrebbero causare danni permanenti allo speaker
o alla fonte di alimentazione.
I prodotti chimici, il sale o “particelle estranee” della piscina o dell’oceano possono
danneggiare le guarnizioni stagne o danneggiare la supercie del connettore nel
corso del tempo, se queste parti non vengono risciacquate dopo l’uso. Dopo averlo
bagnato o risciacquato, non caricare lo speaker nché non è completamente asciutto
e pulito. Caricare lo speaker mentre è ancora bagnato, potrebbe danneggiarlo.
zh-TW 為保護電池的使用壽命請至少每 3 個月對電池充滿一
次電電池續航時間因使用模式和環境條件而異
在未拆除纜線連接的情況下請勿讓 JBL Boombox 3 Wi-Fi 接觸
液體在充電期間請勿讓 JBL Boombox 3 Wi-Fi 暴露於水中
可能導致喇叭或電源出現永久性損壞
如果使用後不沖洗泳池或海洋中的化學物質鹽分或
雜質顆粒會隨著時間的推移而損壞防水密封件或傷害
接頭表面液體溢出或沖洗後請在喇叭乾透且乾淨之後
為其充電潮濕狀態時充電可能會損壞喇叭
DE Lade zum Schutz der Batterie diese mindestens einmal alle 3 Monate
vollständig auf. Die Batterielebensdauer kann aufgrund von Nutzungsverhalten
und Umgebungsbedingungen variieren.
Setze den JBL Boombox 3 Wi-Fi keinen Flüssigkeiten aus, während er über Kabel
verbunden ist. Setze den JBL Boombox 3 Wi-Fi während des Ladevorgangs keinem
Wasser aus. Dies kann zu dauerhaften Schäden am Lautsprecher oder an der
Stromquelle führen.
Chemikalien, Salz oder „Fremdkörper“ in einem Schwimmbecken oder im Meer
können die wasserdichten Dichtungen beschädigen oder die Steckeroberäche
mit der Zeit angreifen, wenn sie nach dem Gebrauch nicht abgespült werden.
Lade den Lautsprecher nach dem Verschütten einer Flüssigkeit oder nach dem
Abspülen erst auf, wenn er vollständig trocken und sauber ist. Das Auaden im
nassen Zustand kann den Lautsprecher beschädigen.
FI Akun käyttöiän suojaamiseksi, lataa täyteen ainakin kerran 3 kuukauden ajalla.
Akun käyttöikä vaihtelee käyttötapojen ja ympäristöolosuhteiden mukaan.
Älä altista JBL Boombox 3 Wi-Fi nesteille irrottamatta kaapeliyhteyttä. Ä
altista JBL Boombox 3 Wi-Fi vedelle latauksen aikana. Se saattaa tuottaa
pysyvän vaurion kaiuttimelle tai virtalähteelle.
Kemikaalit, suola tai vieraat hiukkaset uima-altaassa tai meressä voivat
vahingoittaa vedenpitäviä tiivisteitä tai vahingoittaa liittimen pintaa ajan
mittaan, mikäli niitä ei huuhdella pois käytön jälkeen. Nesteläikkeen tai
huuhtelun tapahduttua, älä lataa kaiutintasi ennen kuin se on täysin kuiva
ja puhdas. Latauksen suorittaminen märässä tilassa saattaa vahingoittaa
kaiutintasi.
RU Чтобы продлить срок службы аккумулятора, полностью заряжайте его
по меньшей мере раз в 3 месяца. Срок службы аккумулятора зависит от
способов использования и условий окружающей среды.
Не подвергайте колонку JBL Boombox 3 Wi-Fi воздействию жидкостей
при имеющемся подключении по кабелю. Не подвергайте колонку
JBL Boombox 3 Wi-Fi воздействию воды во время зарядки. Это может
привести к необратимым повреждениям колонки или источника питания.
Не смытые после использования химические вещества, соль или
«инородные частицы», содержащиеся в бассейне или в океане, могут со
временем повредить водонепроницаемые уплотнители или разрушить
поверхность разъема. После разлива жидкости или промывки не
заряжайте колонку, пока она не станет сухой и чистой. Зарядка во
влажном состоянии может привести к повреждению колонки.
תוחפל האולמב הללוסה תא ןעט ,הללוסה ייח ךרוא לע ןגהל ידכ
HE
שומישה יפואל םאתהב ונתשי הללוסה ייח .םישדוח השול שב םעפ
.הביבסה יאנתו
רוביח תא ריסהל ילבמ םילזונל JBL Boombox 3 Wi-Fi תא ףושחת לא
.הניעטה ןמזב םימל JBL Boombox 3 Wi-Fi תא ףושחת לא .םילבכה
.ןעטמל וא לוקמרל ע ובק קזנל םורגל לולע רבדה
קיזהל םילולע םיב וא הכירבב םירז םימצע וא חלמ ,םיל קימיכ
אל םא ,רבחמה חטשמל וא םימ דגנ םוטיאה תו דוקנל ןמז רובעכ
לע וכפשנ םילזונש רחאל וא הפיטש רחאל .שומישה ירחא ופטשיי
.ןיטולחל יקנו שבי וניא אוה דוע לכ לוקמרה תא ןועטל ןיא ,רצומה
.ול קיזהל הלולע בוטר אוה רשאכ לוקמרה תניעט
Este produto está homologado pela Anatel, de acordo com os procedimentos
regulamentados para avaliação da conformidade de produtos para telecomunicões
e atende aos requisitos técnicos aplicados.
Para maiores informações, consulte o site da Anatel – www.anatel.gov.br
Este equipamento não tem direito à protão contra interferência prejudicial e não
pode causar interferência em sistemas devidamente autorizados.
Atenção: conforme lei brasileira n° 11.291, a exposição prolongada a ruídos
superiores a 85dB pode causar danos ao sistema auditivo.
PT-br Para garantir a durabilidade da bateria, carregue-a totalmente pelo menos
uma vez a cada três meses. A vida útil da bateria depende dos padrões de uso e
das condições do ambiente.
Nunca exponha a JBL Boombox 3 Wi-Fi a líquidos sem antes desconectar os os.
Nunca deixe a JBL Boombox 3 Wi-Fi entrar em contato com água enquanto a
bateria estiver sendo carregada. Isso pode danicar a caixa de som ou a fonte
de energia.
Os selos impermeáveis e a superfície do conector podem ser danicados pela
maresia ou por produtos químicos usados em água de piscina. Por isso, lave a
caixa de som com água após o uso. A caixa de som precisa estar completamente
seca e limpa antes de carregar a bateria. Se a bateria for carregada enquanto a
caixa de som estiver molhada, a caixa de som pode ser danicada.
MM 












 





NL Voor een optimale levensduur de batterij minstens om de 3 maanden volledig
opladen. De levensduur van de batterij is afhankelijk van gebruikspatronen en
omgevingscondities.
Stel de JBL Boombox 3 Wi-Fi niet bloot aan vloeistoen zonder de
kabelverbinding te verwijderen. Stel de JBL Boombox 3 Wi-Fi niet bloot aan
water tijdens het opladen. Dit kan leiden tot permanente schade aan de
luidspreker of stroombron.
Chemicaliën, zout of “schadelijke soen in een zwembad of in de zee kunnen
de waterdichte bescherming of de connector aantasten als ze na gebruik
niet worden afgespoeld. Als je vloeistof hebt gemorst of het apparaat hebt
schoongemaakt, de luidspreker pas opladen als deze helemaal droog en schoon
is. Opladen als de luidspreker nat is kan het apparaat beschadigen.
ID Agar baterai awet, isi dayanya hingga penuh paling sedikit sekali setiap
3 bulan. Masa pakai baterai bervariasi, tergantung pola penggunaan dan
kondisi lingkungan.
Jangan biarkan JBL Boombox 3 Wi-Fi terkena cairan tanpa melepas koneksi
kabel. Jangan biarkan JBL Boombox 3 Wi-Fi terkena air saat mengisi daya.
Cairan atau air dapat merusak speaker atau sumber daya secara permanen.
Bahan kimia, garam, atau partikel asing di dalam air kolam maupun air laut
dapat merusak segel tahan air atau permukaan konektor seiring berjalannya
waktu jika tidak dibilas setelah digunakan. Setelah terkena tumpahan atau
setelah dibilas, jangan isi daya speaker sebelum kering dan bersih sepenuhnya.
Pengisian daya dalam keadaan basah dapat merusak speaker.
EL Για να προστατεύσετε τη διάρκεια ζωής της μπαταρίας, φορτίστε την πλήρως
τουλάχιστον μία φορά κάθε 3 μήνες. Η ζωής της μπαταρίας ποικίλλει ανάλογα με
τη χρήση και τις περιβαλλοντικές συνθήκες.
Μην εκθέτετε το JBL Boombox 3 Wi-Fi σε υγρά χωρίς να αφαιρέσετε το καλώδιο
σύνδεσης. Μην εκθέτετε το JBL Boombox 3 Wi-Fi σε νερό κατά τη φόρτιση.
Μπορεί να προκαλέσει μόνιμη βλάβη στο ηχείο ή στην πηγή τροφοδοσίας.
Χημικές ουσίες, αλάτι ή “ξένα σωματίδια πισίνας ή από τον ωκεανό, μπορούν
να προκαλέσουν ζημιά στις αδιάβροχες μονώσεις ή να βλάψουν την επιφάνεια
του συνδετήρα με την πάροδο του χρόνου, εάν δεν ξεπλυθούν μετά τη χρήση. Σε
περίπτωση διαρροής υγρού ή ξεβγάλματος, μην φορτίζετε το ηχείο σας μέχρι να
στεγνώσει εντελώς και να καθαριστεί. Η φόρτιση όταν είναι βρεγμένο, μπορεί να
προκαλέσει ζημιά στο ηχείο.
HU Az akkumulátor élettartamának védelme érdekében teljesen töltse fel
3 havonta legalább egyszer. Az akkumulátor élettartama a használattól, és a
környezeti feltételektől függ.
A JBL Boombox 3 Wi-Fi készüléket ne tegye ki folyadékoknak a kábelcsatlakozás
eltávolítása nélkül. A JBL Boombox 3 Wi-Fi készüléket ne tegye ki víznek töltés
közben. Ez a hangszóró vagy az áramforrás maradandó károsodását okozhatja.
A medencéjében vagy az óceánban lévő vegyszerek, só vagy „idegen részecskék
idővel károsíthatják a vízálló tömítéseket vagy károsíthatják a csatlakozó
felületét, ha használat után nem öblítik le őket. Folyadék kiömlése vagy
leöblítése után ne töltse fel a hangszórót, amíg teljesen száraz és tiszta nem
lesz. A nedves állapotban történő töltés károsíthatja a hangszórót.
zh-CN 为了保护电池寿命请每至少 3 个月进行一次满充。
池寿命因使用方式和环境条件而异。
在拔除电线之前请勿将 JBL Boombox 3 Wi-Fi 置于液体之中。
此外充电时请勿将 JBL Boombox 3 Wi-Fi 置于水中。因为可能
会对扬声器或电源造成永久损坏。
如果使用后不冲洗久而久之泳池或海洋中的化学物
质、盐分或“杂质颗粒物”会损坏防水密封层或连接器表
面。若有液体漏出或进行了冲洗,在完全干燥和干净之
请不要给扬声器充电。潮湿状态下充电可能会损坏
您的扬声器。
SV För att öka batteriets livslängd ska du ladda det fullt minst en gång var tredje
månad. Batteriets livslängd varierar beroende på användningsområden och
miljöförhållanden.
Utsätt inte JBL Boombox 3 Wi-Fi för vätskor utan att ta koppla från strömkabeln.
Utsätt inte JBL Boombox 3 Wi-Fi för vatten under laddning. Det kan leda till
permanent skada på högtalaren eller strömkällan.
Kemikalier, salt och små partiklar i din pool eller i havet kan skada de vattentäta
tätningarna eller skada kontaktytan med tiden om de inte sköljs av efter
användning. Om högtalaren har fått vätska på sig eller är avsköljd får den inte
laddas förrän den är helt torr och ren, annars kan den skadas.
NO For å beskytte batteriets levetid må det lades helt opp minst én gang hver 3.
måned. Batteriets levetid vil variere etter bruksmønster og omgivelsesforhold.
JBL Boombox 3 Wi-Fi skal ikke utsettes for væsker uten at ledningene er trukket
ut først. JBL Boombox 3 Wi-Fi skal ikke utsettes for vann under lading. Det kan
føre til permanent skade på høyttaleren eller strømkilden.
Kjemikalier, salt eller “fremmedpartikler i bassenget eller havet kan skade de
vanntette pakningene eller skade koblingsoveraten over tid dersom disse ikke
skylles etter bruk. Etter vannsøl eller skylling må du ikke lade høyttaleren før
den er helt tørr og ren. Hvis den lades mens den er våt, kan høyttaleren skades.
JP 持続時間保護最低3か月1はフ
充電駆動時間は使用
環境条件
JBL Boombox 3 Wi-Fi続しまま
でく JBL Boombox 3 Wi-Fi充電中は水
濡らスピまた
修復不可能損傷場合
は海使用後淡水
は海化学物質
たは「異物」たは
損壊原因可能性
は水後は完全清潔
電しまま
破損修理不可能
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries,
Incorporated is under license. Other trademarks and trade names are those of their
respective owners.
Wi-Fi CERTIFIED 6™ and the Wi-Fi CERTIFIED 6™ Logo are trademarks of Wi-Fi Alliance®.
Активная акустическая система
Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США,06901 Коннектикут,
гтэмфорд, Атлантик Стрит 400, офис 1500
Сделано в Китае
Импортер: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, госква, ул. Двинцев, д.12, к. 1
Гарантийный период: 1 год
Срок службы: 2 года
Информация о сервисных центрах: www.harman.com/ru
Техническая поддержка: 8 (800) 700 0467
Организация, уполномоченная на принятие претензий потребителей: OOO “ХАРМАН
РУС СиАйЭс“
Товар сертифицирован
Дата изготовления устройства определяется по двум буквенным обозначениям из второй
группы символов серийного номера изделия, следующих после разделительного знака «-».
Кодировка соответствует порядку букв латинского алфавита, начиная с января 2010 года:
000000-MY0000000, где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и
«Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.).
Google, Android, Google Play and Chromecast built-in are trademarks of Google LLC.
Use of the Works with Apple badge means that an accessory has been designed to
work specically with the technology identied in the badge and has been certied
by the developer to meet Apple performance standards.
Apple, and AirPlay are trademarks of Apple Inc., registered in the U.S. and other countries.
To control this AirPlay 2–enabled speaker, iOS 13.4 or later is required.
Amazon, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its aliates.
Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.
com/connect to learn how.
The Spotify Software is subject to third party licenses found here:
https://www.spotify.com/connect/third-party-licenses.
1. Information on power consumption
This equipment complies with European Commission Regulation (EC) No 1275/2008 and
(EU) No 801/2013.
O: N/A
Standby (when all wireless connections are deactivated): < 0.5 W
Networked standby: < 2.0 W
2. The period of time after which the power management function switches the equipment
automatically into:
O N/A
Standby When all wired ports are disconnected
and all wireless network connections
are deactivated
Switched to standby mode after
10 minutes.
Networked
standby
When any wireless network connection
is activated
Switched to networked standby
mode after 10 minutes of inactivity in
operational mode
3. If this equipment has the wireless network connections:
How to activate wireless network connections:
Set up the equipment properly;
Switch into wireless mode (Bluetooth, Chromecast built-in™, AirPlay 2 casting audio, Alexa
Multi-Room Music & etc);
Connect with energy using products (e.g. players/ game consoles/ STB (Set-Top Boxes)/
phones/ tablets /PCs).
Use Restriction: This device is restricted to indoor use when operating in
the 5150 to 5350 MHz frequency range in following countries:
BE EL LT PT
Belgium (BE), Greece (EL),
Lithuania (LT), Portugal (PT),
Bulgaria (BG), Spain (ES),
Luxembourg (LU), Romania
(RO), Czech Republic (CZ), France
(FR), Hungary (HU), Slovenia
(SI), Denmark (DK), Croatia
(HR), Malta (MT), Slovakia
(SK), Germany (DE), Italy (IT),
Netherlands (NL), Finland (FI),
Estonia (EE), Cyprus (CY), Austria
(AT), Sweden (SE), Ireland (IE),
Latvia (LV), Poland (PL) and
Northern Ireland (UK).
BG ES LU RO
CZ FR HU SI
DK HR MT SK UK
DE IT NL FI
EE CY AT SE
IE LV PL UK(NI)
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
PA_JBL_Boombox 3 Wi-Fi_QSG_Global_DV2_V3.indd 2PA_JBL_Boombox 3 Wi-Fi_QSG_Global_DV2_V3.indd 2 6/10/2022 11:27:01 AM6/10/2022 11:27:01 AM

Содержание

Похожие устройства

Скачать
Случайные обсуждения
