Lenco LS-101 BLACK [8/85] Bluetooth out operation

The PITCH CONTROL allows you to fine tune the playing speed of the record once the correct speed

(33/45/78 RPM) is chosen. Rotate the PITCH CONTROL to slightly increase or decrease the speed of the

turntable if necessary.

To stream your record music to external Bluetooth speakers (not included), see the BLUETOOTH OUT

OPERATION section.

3. Bluetooth out operation

This turntable supports Bluetooth wireless connection ( OUT). It can be connected with external Bluetooth

compatible headphones (not included) or Bluetooth speakers (not included).

1. Turn on the unit by the POWER/VOLUME Knob.

2. Rotate the FUNCTION SELECTOR to select the OUT mode.

3. The POWER/FUNCTION INDICATOR will light "blue" and begin to flash

slowly.

4. Turn ON your external Bluetooth receiving device (such as Bluetooth

headphones or Bluetooth speakers) and set to pairing mode.

5. When pairing is successful, the POWER/FUNCTION INDICATOR will stop

flashing and remain lit "blue".

6. You are now connected to your external Bluetooth device.

7. Begin playing a record, the sound will be heard from the external Bluetooth device.

Note: You can ONLY adjust the volume using the volume control on your external Bluetooth device.

Notes:

• Place the Bluetooth device within 3 feet (1m) from the turntable to enable them to pair correctly.

• The turntable stays in the pairing mode for only 30 seconds. If pairing is not properly completed within

30 seconds, repeat Step 2 till 4 again after turning all devices OFF.

• “ OUT” only works in PHONO mode. OUT will NOT work in the AUX IN or regular Bluetooth ( IN)

function modes.

4. Listen to Bluetooth

An external device with Bluetooth Connectivity like a smartphone or tablet be wirelessly connected to this

Turntable using the Bluetooth function.

1. Turn on the unit by the POWER/VOLUME Knob.

2. Rotate the FUNCTION SELECTOR to select the IN mode.

3. The POWER/FUNCTION INDICATOR will light "blue" and begin to flash.

4. The first time you use your Bluetooth device with the turntable, you will

need to pair them together.

5. Turn your external device’s Bluetooth Setting ON. Wait a moment, then

look for the Bluetooth pairing name “Lenco LS-101”. If your device asks

for a password (depending on the device manufacturers, model, and

software version), then enter digits “0000” and press OK.

6. Select the Bluetooth pairing name, to connect the unit. Once connected, the Led light will stop flashing.

7. You are now connected to your external device via Bluetooth

8. Rotate the Volume Control Knob to adjust the sound level and adjust the volume control at your external

audio device.
