JUPITER

Installation of shower system

Check the kit delivery before installation and make sure you have all the necessary components for

the shower system. If any parts are missing, please contact your dealer.

Installation of mixer

1. Hot and cold water outputs with internal thread G1/2 should be installed at a distance between

the centers of 150 ± 15 mm from each other. The left output is for hot water pipe, the right one is

for cold water pipe.

2. Before installing the mixer, it is necessary to equalize the pressure of cold and hot water with

the help of valves regulating the water supply to the room.

3. Turn o󰀨 the water system.

4. Screw eccentric adapters into the output holes of water supply system, having previously

sealed the threaded part with an insulating material. Select position of the eccentric adapters,

where they coincide and correspond to the connecting position of the mixer.

5. It`s recommended to connect the mixer with the aerator removed (unscrewed) in order to avoid

clogging at the rst start-up of water.

6. If there are decorative sockets, install them on the eccentric adapters.

7. Install rubber gaskets on the water inlet holes into the mixer body and, using a tool with soft

lining, attach the mixer body.

8. Turn on the water supply system, check the tightness of all connections when the mixer is

closed. If necessary, perform additional tightening and sealing of the joints.

9. Open the hot and cold water supply for a short period of time, then close the water supply and

install (tighten) the aerator in place.

Installation of shower system rod with mixer

1. Install the rod on the mixer body and tighten the nut. Make sure that the rubber gasket is inside

the rod.

2. Adjust the length of the rod and x the position of the wall bracket, then use a pencil to mark

the fastening on the wall.

3. Remove the rod, loosen the fastening of bracket with a hexagon and install it in the marked

place, mark the central hole with a pencil, drill the hole with a diameter of 6 mm with an electric drill.

4. Insert the dowel into the drilled hole, then use the self-tapping screw and a phillips screwdriver

to x the bracket on the wall.

5. Screw the shower rod to the mixer body. Make sure that the rubber gasket is inside the rod.

Then insert the shower rod into the wall bracket and x it with a screw in the wall bracket using

a hexagon.

6. Fix the overhead shower on the shower rod by rotating it clockwise.

7. Screw the hose into the water outlet connector, which is located at the bottom of the mixer body.

8. Screw the hand shower to the hose and make sure there are gaskets.

9. Insert the hand shower into the shower holder slider.

10. Using the nut on the rod above the bracket you can adjust the length of the rod.

11. Check the tightness of the connection of all parts after installation. Turn on the water

and check for no leakage in each connecting part.
