JUPITER

Installation of shower system rod without mixer

1. Attach the shower rod to the wall.

2. Adjust the length of the rod and x the position of the wall bracket, then use a pencil to mark

the fastening on the wall.

3. Remove the rod, loosen the fastening of bracket and switcher with a hexagon, install them in

the marked places, mark the central holes with a pencil, drill holes with a diameter of 6 mm with

an electric drill.

4. Insert the dowels into the drilled holes, then use a self-tapping screw and a phillips screwdriver

to x the fasteners on the wall.

5. Insert the shower rod with the wall bracket into the upper fastening, and the switcher into the

lower fastening. Fix it with a screw and a hexagon.

6. Install the water supply hose from the mixer to the second outlet of the switcher from the wall

by turning the nut, make sure there is a gasket.

7. Connect the hand shower hose to the rst outlet of the switcher from the wall by turning the nut,

make sure there is a gasket.

8. Connect the hand shower and the hose, make sure there is a gasket.

9. Check the tightness of the connection of all parts after installation. Turn on the water and check

for no leakage in each connecting part.

General recommendations

Mixer care

Cleaning agents are required to remove lime deposits.

Follow these rules during cleaning:

1. Never use products containing hydrochloric, formic or acetic acid, as they can cause signicant

damage.

2. For the same reasons, it is recommended to use phosphoric acid on a limited scale.

3. Never mix di󰀨erent cleaning products.

4. Never use abrasive cleaners or devices (for example, some cleaning powders and microber

sponges).

Mixers care recommendations

Modern plumbing equipment, kitchen and shower faucets are made of a variety

of materials depending on the functional features and design that are in demand

in the market. To avoid damage when cleaning take certain criteria into account.

Follow the instructions of the manufacturer of cleaners, as well as the following rules for their use:

1. Use cleaning agents when required, according to the instructions for use.

2. The dosage and duration of treatment with cleaning agents should be selected taking into

account characteristics of the product (mixers should not be exposed to cleaning agents longer

than required).

3. Regular care can prevent calcication.
