– 2

1 Hose coupling

2 Stopper / retract

3 Hose

4 Stopper

5 Metal bow

6 Handle

7 Wall mount

8 Fastening material

9 Tap connection with reduction fitting

10 Padlock (not included in the delivery)

11 Accessory compartment

12 Connection hose

13 Carrying handle

14 Spray nozzle

Illustration

 Mark the bores to mount the wall mount

and place dowels into the drilled bores.

 Fasten the wall mount using the includ-

ed washers and screws.

Illustration

 Place the hose box flush with the metal

bow and hook it in. Make sure that all 4

screw heads protrude from the hook

holes.

Slide the metal bow downwards verti-

cally all the way.

Illustration

 Attach the accessories holder to the

bottom side of the metal bow.

Illustration

 To change the swivel range, pull the left

or the right stop toward the outside and

swivel the hose box into the desired po-

sition.

(The swivel range of the hose box can

be swivelled in 30°-steps.)

Let the stop lock in in the desired posi-

tion.

Illustration

 Loosen both screws on the stopper.

 Slide the stopper to the desired position

and screw it in.

Illustration

 The product can be protected against

theft. Use the padlock for this.

Note

Make sure the hose has free return play. It

should not be too dirty when it is coiled to

ensure the proper function of the automatic

retraction/recoiling.

 Connect the connecting hose to the wa-

ter tap.

 Open tap.

 Pull the hose out to the desired length.

The stop function of the hose box can

be activated in < 50 cm-steps and can

be noticed by a clicking sound.

 Attach the Kärcher garden accessories

to the hose coupling.

 Trigger the automatic recoiling function

by briefly pulling on the hose.

 The garden hose is coiled up evenly.

 Turn off tap.

Operation

Product description

Preparing the Appliance

Operation

Unroll the hose

Coil the hose

Finish operation

9EN
