5English

OPERATION

1. Li-battery or battery adapter AA can be used for operation with line

laser. If using a battery adapter AA, install batteries in it. Open the

battery compartment cover. Insert the batteries into the battery

adapter. Close the battery compartment cover. Install Li-battery /

battery adapter AA (11) on the housing of the line laser. To replace

the Li-battery / battery adapter press clip (10) and release it from the

housing of the line laser.

2. To check the power level of the Li-battery use power indicator (9).

To do this, press the button with the battery icon. The number of

highlighted segments on the indicator shows the power level. It is

possible to use charger to operate with the tool. Use charger for

rechargeable batteries. Connect the charger to the connector for

power switch (13) that is located on the housing of the line laser. Line

laser will be ON and charge rechargeable batteries.

WARNING: Never use charger for ordinary batteries. Do not leave

the line laser unattended while using charger. Parameters of

the charger must correspond to the parameters of domestic

electricity. Output voltage must be no more than 12V.

KEYPAD

1. Horizontal switch (H)

2. P o w e r s w i t c h O n / O  ( P o w e r L E D )

3. Vertical switch (V)

4. Detector LED

5. Detector mode

6. Self-leveling mode

7. Self-leveling o LED
