6 English

3. Set up the line laser on the oor or the tripod. When using tripod,

screw the tripod screw into the centering hole. Use screw-adapter

to set a line laser on the mounts with bases. Level the line laser

with the bubble level with the help of adjustable legs (7) or tripod.

Press button (2) to switch on the line laser. Press buttons H (1) and

V (3) to switch and select vertical and horizontal lines. Switch o the

unnecessary lines to save battery power.

Variants of projections:

H button:

- 1 horizontal line (sector 120º)

- 2 horizontal lines (sector 180º)

- 4 horizontal lines (sector 360º)

- all horizontal lines are switched o

V button:

- one vertical line and plumb down

- two vertical lines and plumb down

- 4 vertical lines and plumb down

- all vertical lines are switched o

5. Switch On the line laser. Automatic self leveling begins. LED (7) blinks.

When the self-leveling is nished, LED (7) is OFF. If the LED (7) and

the laser beam begin to blink, the deviation of the line laser from the

horizontal plane is more than ±3º. Laser level can’t be self-leveled.

Adjust the line laser with the help of adjustable legs or tripod.

6. Rotate the housing of the line laser to aim the vertical beams. Use

switch (12) for ne adjustment. Use limb (6) to rotate the housing by

the specic angle:

- aim the vertical beam to the selected point.

- rotate the switch (12) to coincide the mark on the housing witht the

selected rotation angle value on the limb.
