6 English

TO CHECK THE ACCURACY OF LINE LASER (SLOPE MODE)

Set up the instrument between two walls, the distance is 5 m. Turn on the

line laser and mark the point of cross laser line on the wall. Turn the line

laser by 180º and mark again the point of cross laser line. Set up the line

laser 0,5-0,7m away from the wall and make, as described above, the same

masrks. If the dierence {a1- b2} and {b1-b2} is less then the value of “ac-

curacy” (see spesications), there is no need in calibration.

Example: when you check the accuracy of Line Laser the dierence

is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-

{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.

If the accuracy of line laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

TO CHECK THE ACCURACY OF HORIZONTAL LINE (BENDING

PLANE)

Choose a wall and set laser 5M away from the wall. Turn on the laser and

mark the point of cross laser line. Rotate the line laser to shift the beam

approximately 2.5m to the left and check that the horizontal line is within

the “accuracy” value (see characteristics) at the same height as the mark

indicated by the laser cross. Repeat the same procedure shifting the line

laser to the right. Note: do not move the rotating axis when checking the

accuracy.

TO CHECK PLUMB

Choose a wall and set laser 5 m away from the wall. Hang a plumb with the

length 2.5 m on the wall. Turn on the laser and make the vertical laser line

meet the point of the plumb. The accuracy of the line is in the range if the

vertical line doesn’t exceed (up or down) the accuracy that is shown in the

specications (e.g. ±3 mm/10 m). If the accuracy isn’t corresponding with

claimed accuracy, contact the authorized service center.

PRODUCT LIFE

Product life of the tool is 7 years. The battery and the tool should never
