4 English

LASER LINES

FEATURES

1. Vertical laser beam (V) / Horizontal laser beam (H)

2. Detector mode

3. Battery compartment

4. Tripod mount 1/4’’

5. Compensator switch (ON/X/OFF)

6. Vertical laser window

7. Horizontal laser window

SAFETY INSTRUCTIONS

Please follow up instructions given in operating manual. Do not stare into

beam. Laser beam can lead to eye injury (even from greater distances).

Do not aim laser beam at persons or animals. The laser plane should be

set up so that the beam path is not at normal eye level. Use the line laser

for measuring jobs only.

Do not open line laser housing. Repairs should be carried out by autho-

rized workshops only. Please contact your local dealer. Do not remove

warning labels or safety instructions. Keep line laser away from children.

Do not use line laser in explosive environment.

OPERATION

Cube 2-360 Green is a reliable and convenient line laser. It will be irreplace-

able instrument for many years.

1. Before use, remove battery compartment cover. Insert three batteries

into battery compartment with proper polarity, then put the cover back.

2. Set the compensator locking grip (5) into ON position.

If the switch is ON,that means the power is on and the compensator is working.

If the switch (5) is in intermediate position, that means the power is opened,the

compensation is still locked, but it will not warn if you issue the slope. It’s

the hand-mode.
