INSTALLATION

Step 1: Connect the supplied AC power cord to the back of the

chassis.

Step 2: Attach the plug into a standard AC outlet with a voltage

range from 100~240Vac.

Step 3:Turn on the chassis system by flipping the switch

beside the receptacle to ON position. The LED on the

front panel of power supply will come on then.

Installing and Removing the Power Supply

 To remove a power supply out the chassis, you have to

loose the hand screw counter clockwise and pull out

the power supply from the chassis.

 To install a power supply to the chassis, you have to

fasten the hand screw clockwise and slide in the power

supply to the chassis.

Y o u c a n s l i d e i n a n d o u t t h e p o w e r s u p p l y f r o m t h e b a y ,

f a s t e n o r l o o s e t h e h a n d s c r e w c l o c k w i s e o r c o u n t e r

c l o c k w i s e b y u s i n g h a n d o r s c r e w d r i v e r .
