Maintenance
ATTENTION! The fan and auxiliary control equipment should be isolated from the power supply during
installation and/or maintenance. The equipment should be grounded (for 250, 315 models).
Malfunction Probable cause Troubleshooting method
When connected to the mains, the
fan does not rotate, it does not
respond to controls.
Power supply is not connected.
It was necessary to address a specialist.
Malfunction in the internal connection
Low air consumption. Clogged ventilation system. Clean the ventilation system.
Increased noise or vibration.
Impeller is clogged. Clean the impeller
Fan is not secured or it is incorrectly
mounted.
Eliminate the installation error.
Clogged ventilation system. Clean the ventilation system.
Burning odor. The mains wire is connected to L1 and L2. Connect the wires correctly.
Connecting the fan to the mains
The fan has two speeds. Depending on the required fan performance, the phase of the power supply is switched between
the terminals:
For models with flange diameter from 100mm to 315mm
• L1 Low Speed
• L2 High Speed
When setting a high fan speed, depending on the model, it is necessary to connect the fan as follows: L2 (phase of the
supply network), N (neutral of the supply network), protective earth (for models 250, 315).
When setting a low fan speed, it is necessary to switch the phase of the supply network from terminal blocks L2 (phase)
to terminal blocks L1 (phase), connection N (neutral of the supply network), the protective ground remains unchanged (for
models 250, 315).
ATTENTION! In order to avoid damage to the fan, do not simultaneously connect a phase of the supply mains to
terminals L1 and L2.
ATTENTION! All work on installation and connection of fans should be carried out only with the mains voltage
removed.
The fans shall be connected by electricians who have a special permit for the work performed.
Means for disconnecting from the mains supply should be built into the fixed wiring, in accordance with the installation
regulations. The disconnecting device should disconnect all poles. The grounding conductor should not break.
The fan and auxiliary control equipment should be isolated from the power supply during installation and/or maintenance.
The equipment should be grounded (for 250, 315 models).
Please remove the cover from the terminal box, study the wiring diagram (Fig. 2 or Fig. 3), and make the necessary
connections. Check whether a ground connection exists (for 250, 315 models).
After finishing the connection work and checking the connections to the terminal box, move the cover and make sure it is
fixed.
Installation: The length of the firmly installed piping from the fan should be at least 500mm on each side.
When connecting TYPHOON fan with IP44, it is required to pass a network cable with a diameter of at least 4 mm through
a cable gland.
The cable gland is designed for sealed input-output of cables from wires in switchboard enclosures.
The compression nut design has special locking notches to prevent self-loosening. A protective diaphragm
prevents dust from entering the enclosure and achieves a degree of protection IP44 and above.
Maintenance
• Disconnect the fan from the mains;
• Dismantle the fan by disconnecting the middle unit and removing it from the installation site;
• Remove dust from impeller blades using a soft dry brush or cloth;
• Clean the fan impeller blades using a detergent solution;
• Wipe all plastic parts with a soft cloth dampened with soapy water;
• Wipe all surfaces dry;
• Assemble the fan and reinstall;
• Cleaning is recommended every 6 months.
ATTENTION!
Do not get the cleaning solution on the electric motor!
Water entering the fan is not allowed!
Decommissioning and disposal
At the end of their service life or failure of the fan or its components, they should be disposed of. Disposal shall be carried out
separately, according to material groups: plastic elements, metal fasteners.
ATTENTION!
Dismantling and disassembly of the fan should be carried out by qualified specialists with a complete disconnection
from the power supply.
Service life The established service life is 5 years. At the end of its service life, if the fan has not lost its
functionality, it is used until it fails.
Manufacturer’s warranty
The manufacturer shall guarantee the normal operation of the fan for 3 years (for models 100-160) and 1 year (for models 200-
315) from the date of sale in a retail network, provided that the rules for transportation, storage, installation, operation, and
other requirements of this instruction. In the absence of a mark on the date of sale, the warranty period shall be calculated
from the date of manufacture. In case of malfunctions in the fan operation due to the manufacturer’s fault during the warranty
period, the consumer has the right to replace the fan at the manufacturing plant, provided that the serial numbers on the
product and in the passport match.
The product meets the requirements of
TR CU 004/2011 On the Safety of Low-Voltage Equipment;
TR CU 020/2011 Electromagnetic Compatibility of a Technical Equipment;
TR CU 037/2016 On the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products.
Certificate details:
EAEU Certificate of Conformity No. RU C-RU.АД07.В.01907/20
Valid from September 4, 2020, to September 3, 2025
Series RU No. 0223890
Issued by the product certification body VELES Certification Center, LLC. Address: Nikolsky Lane, building 4, letter A, room 8H,
190068, St. Petersburg, Russian Federation.
Declaration details:
EAEU Declaration of Conformity N RU Д-RU.КА01.В32655/20.
Valid from August 31, 2020, to August 30, 2025
Disposal
This appliance is marked, in accordance with European Directive 2012/19/EU on the disposal of old electrical and electronic
equipment (waste electrical and electronic equipment – WEEE). This Directive defines the EU-wide rules for the collection and
disposal of old appliances.
Storage and transportation rules
It is necessary to store the fan only in the manufacturer’s packaging in a ventilated room at a temperature from -10 °C to +40
°C and a relative humidity of no more than 80% (at T = 25 °C). Shelf life is 2 years from the date of manufacture. Products
shall be transported by any type of transport, provided that consumer or shipping containers are protected from the direct
impact of atmospheric precipitation, from the absence of displacement of transport places during transportation, from the
absence of mutual shocks during transportation and while ensuring the safety of the fans. Transportation shall be carried out,
in accordance with the rules in force for this mode of transport.
Thank you for choosing us!
