Ritar EV12-100S Описание акб ev12-100S (ENG) онлайн

Ritar EV12-100S Описание акб ev12-100S (ENG) онлайн
Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV12-100S(12V100Ah)
Cells Per Unit
6
Voltage Per Unit
12V
Capacity
100Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 30.0 Kg (Tolerance±5%)
Max. Discharge Current
1000A (5 sec)
Internal Resistance
≤5.5 mΩ (Full Charge Condition @25℃)
Terminal
Default F12(M8), F15(M6)&L4 Optional
Maxi. Charging Current
30.0A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
13.6 V~13.8 V @ 25℃
14.6 V~14.8 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
620A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
C3 75.0Ah
C20 .0Ah 100
C5 85.0Ah
C10 95.0Ah
ISO 90 01 ISO 14 001 ISO 45 001
MH 28539
BSTXD210316008503EC
Length
Width
Height
Total Height
306.5±2mm (12.1 inches)
168.5±2mm (6.63 inches)
210±2mm (8.27 inches)
215±2mm (8.46 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit mm
:
210
306. 5
F12 Terminal
5
M8
Φ16
168.5
215
24
238
F.V/Time 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 241.1 191.0 111.7 61.1 36.2 28.2 22.2 18.9 12.4 10.0 5.21
1.65V 227.9 182.6 107.2 59.0 35.1 27.3 21.6 18.4 12.3 9.90 5.12
1.70V 209.8 171.0 102.5 57.1 33.9 26.6 21.0 17.9 12.1 9.75 5.06
1.75V 192.0 159.1 98.0 55.0 32.7 25.8 20.4 17.4 11.9 9.62 5.00
1.80V 173.8 146.9 93.6 52.9 31.6 25.0 19.9 17.0 11.7 9.50 4.95
1.85V 142.1 121.9 80.6 47.4 28.9 23.1 18.5 15.8 11.0 8.94 4.70
F.V/Time 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 409.9 333.8 202.9 114.8 68.7 53.9 42.6 36.4 24.2 19.7 10.3
1.65V 394.8 323.9 196.8 111.5 66.8 52.4 41.6 35.5 24.0 19.5 10.1
1.70V 370.1 307.9 190.0 108.6 65.0 51.2 40.6 34.7 23.7 19.2 10.0
1.75V 344.9 290.7 183.5 105.2 63.0 49.9 39.7 34.0 23.4 19.0 9.88
1.80V 317.7 272.2 177.1 101.8 61.0 48.5 38.7 33.2 23.0 18.8 9.80
1.85V 264.2 229.1 154.1 91.9 56.2 45.1 36.1 31.1 21.7 17.7 9.32
