ENI MULTITECH THT corresponding oils:

Mobil Mobiluid 424 Mobil Mobiluid 426 Petronas Arbor MTF Special 10W-30

Shell Spirax S4 TXM Total Dynatrans MPV Elf Tractelf BF16

Castrol Agri Trans Plus 80W Chevron Textran THD Premium Q8 Roloil Multivariax 35 HP

WARNING

• As far as engine lubricants are concerned, refer to the relative operating and maintenance manuals.

IDENTIFICATION OF COMPONENTS

Refer to gures 1 to 4.

1 - Pump

2 - Petrol/gasoline engines

3 - Frame

4 - Handle

8 - Warning plate

9 - Accessory rack

11 - Water inlet hose-end tting

12 - Water inlet hose clamp

13 - ID plate

14 - Base

15 - Water outlet tting

16 - Water inlet tting

17 - Pressure regulating knob

18 - Pressure indicator

19 - Spray gun

20 - Thermal valve

21 - Single barrel lance hose

24 - Single barrel nozzle holder head

25 - Detergent tank

26 - Detergent tank cap with dosing device

27 - Oil plug with vent for pump

29 - Nozzle cleaning needle

30 - High pressure hose

31 - Detergent suction hose

32 - Spray gun lever safety stop

33 - Spray gun lever

34 - High pressure hose quickt coupling

36 - Detergent suction tting

37 - Detergent suction hose clamp

38 - Pump oil level indicator

39 - Water inlet lter

40 - Detergent suction lter

44 - Gearbox oil level indicator (2W PRO)

46 - Oil plug with vent for gearbox (2W PRO)

SAFETY DEVICES

• Pressure unloader/regulation valve

Valve, suitably calibrated by the Manufacturer, for regulating work pressure by means of a knob (17)

and that allows the pumped uid to return to pump suction thus preventing the onset of dangerous

pressures when closing the spray gun or when trying to set a pressure that is above the maximum

permitted values.

• Spray gun lever lock device.

Safety stop (32) for locking the spray gun (19) lever(33) in the closed position so it cannot be started

accidentally (Fig. 3, position S).

• thermostatic valve: designed to prevent the pump gaskets from overheating during prolonged

operation in bypass.

STANDARD FITTING

Make sure the following are inside the pack of the product you have purchased:

• high pressure cleaner;

• high pressure delivery hose;

• spray gun;
