Not for

Reproduction

• Always be aware of the direction the snow is being

thrown.

1. Turn the chute rotation crank (D, Figure9) to set the

direction of the discharge chute.

2. Use the deflectorcontrol lever(C) to move the deflector

up or down. Raise the deflector to throw snow farther.

3. Use the speed control lever (B) to select the forward or

reverse drive speed. Use lower speeds to remove wet,

heavy snow. Use higher speeds for light snow.

Note:Make sure to release the traction control lever (F)

before you change speeds.

Engaging the Auger and Impeller

DANGER

The snowthrower contains a rotating auger and impeller that

throws snow. Fingers or feet can quickly become caught in

the rotating auger or impeller, which can result in traumatic

amputation or severe laceration.

1. Push and hold down the auger control lever (A, Figure

10) to engage the auger and impeller.

2. Release the auger control lever to disengage the auger

and impeller.

• If the auger and impeller does not stop in five

seconds adjust the control cable. SeeAdjusting the

Auger andImpeller Control Cables.

• If the auger and impeller still does NOT stop in five

seconds, see an Authorized Service dealer.

Engaging the Drive Wheels

NOTICE DO NOT move the speed control lever while the

traction control lever is engaged. This can result in damage

to the drive system.

1. To move the snowthrower forward, set the speed control

lever (B,Figure11) to one of the forward positions.

2. Select a lower number for heavy snow, a middle number

for light snow, and a higher number to transport the

snowthrower.

3. Push and hold down the traction control lever (F).

4. To move the snowthrower in reverse, set the speed

control lever to R1 or R2.

5. Push and hold down the traction control lever.

6. To stop the snowthrower, release the traction control

lever. The unit will stop immediately. 

• If the unit does not stop, adjust the control cable.

SeeAdjusting the Traction Control Cable.

• If the unit still does not stop, see an Authorized

Service Dealer.

Note:If you remove snow at too fast of a rate, it will overload

the machine capacity.

Using the Free Hand™ Feature

After the traction control and auger control is engaged, the

Free Hand™ feature, lets the operator release the auger
