MEASUREMENT FOUNDATION

GroundDrill-15 HERCULES

MAINTENANCE OF AIR FILTER

A dirty air lter will restrict air ow to the carburetor, reducing engine performance. If you operate the engine in very dusty areas, change

the air lter more often than specied in the maintenance schedule.

a) Remove the air lter cap. Detach the element;

b) Check the condition of the paper ltering element. Damaged or durty element must be changed.

c) Put the detail on its place.

Caution: Never use gasoline or other dissolvents to clean air lter. Ignition could result. Operating the engine without an air lter, or with

a damaged air lter, will allow dirt to enter the engine, causing rapid engine wear.

CLEANING OF THE FUEL TANK AND CARBURETOR

Caution: Gasoline and its vapors are extremely ammable and explosive. Fire or explosion

can cause severe burns or death. Don’t smoke on the worksite. Keep gasoline away from

sparks, open ames, pilot lights, heat, and other ignition sources.

1. Place the gasoline container below the carburetor. Use a funnel to avoid spilling the fuel.

2. Remove the carburetor drain bolt and sealing washer.

3. After all the fuel has drain into the container, reinstall the drain bolt and sealing washer.

Tighten them securely.

SPARK PLUG SERVICE

Recommended spark plugs: F7RTC or other equivalents.

Caution: An incorrect spark plug can cause engine damage. Install spark plug with correct electrode gap. Avoid thing coating on it.

1. Remove the spark plug with a spark plug wrench.

Caution: Mufer is very hot during engine running. Be careful, don’t touch it until it gets cold.

2. Inspect the spark plug.

3. Replace it if the electrodes are worn, or if the insulator is cracked or chipped.

Carburetor

float bowl

Sealing washer

Drain bolt
