9 ENGLISH
Disposing of dust
CAUTION: Empty the cleaner before it
becomes too full, or the suction force weakens.
CAUTION: Be sure to empty the inside of the
cleaner itself of dust. Failure to do so may cause the
ltertobecloggedorthemotortobedamaged.
Inordertodropduststickingonthelterinthecapsule,
tap the capsule 4 or 5 times with your hand.
►Fig.6: 1. Capsule 2.Suctioninlet
Pointthesuctioninletdownwards,turnthecapsulein
direction of the arrow as illustrated, and disconnect the
capsule slowly and straight.
►Fig.7: 1. Capsule 2.Suctioninlet
NOTE: Be sure to set a garbage bag beneath the
capsule, as dust may spill out when the capsule is
opened.
Remove accumulated dust from inside of the capsule
andoffoftheprelter.
►Fig.8: 1.Prelter2. Capsule
Twisttheprelterindirectionofthearrowtounfasten
the securing lip from the cleaner unit and then pull off
theprelter.
►Fig.9: 1.Prelter2.Securinglip
Cleanoutnedustfromtheprelter.Andthen,pulloff
thelterandlightlytapittoremovedust.
►Fig.10: 1. Filter 2.Prelter
Reassembly
Putonthelterfullyinpositiononthecleanerunit.
►Fig.11: 1. Filter
NOTICE: Make sure the lter is put on straight
without being peeled back.Ifthelterisputon
incorrectly as illustrated, dust will get into the motor
housing, and cause a motor failure.
►Fig.12: 1. Filter
Installtheprelter.Atthistime,makesuretotwistthe
preltersothatthesecuringlipisrmlylockedinthe
cleaner unit.
►Fig.13: 1.Prelter2.Securinglip
►Fig.14
Install the capsule. Align the mark on the capsule with
themarknearthehandleandthenrmlytwistthecap-
sule in direction of the arrow until it is secured.
►Fig.15: 1. Capsule 2. Handle 3.Mark
NOTE: Always remove dust ahead of time, as the
suction power will be reduced if there is too much
dust in the cleaner.
NOTICE: Always be sure to check that both the
lter and prelter are loaded correctly prior to
using the cleaner. If they are not loaded correctly,
dust will get into the motor housing, and cause a
motorfailure.Ifthefollowingexamplesoccur,thelter
andprelterarenotloadedcorrectly.Reloadthem
correctly to rectify problem.
Problem Examples
Example1:Onlytheprelterhasbeenloaded(nolter)
►Fig.16: 1.Prelter
Example2:Onlythelterhasbeenloaded(noprelter)
►Fig.17: 1. Filter
Example3:Thelterhasbeenloadedinapeeledback
state
►Fig.18: 1. Filter
Example4:Thesecuringlipontheprelterisnotrmly
locked in the groove of cleaner housing
►Fig.19: 1.Securinglip2.Prelter3. Groove of
cleaner housing
OPERATION
CAUTION: To connect attachments, such
as nozzle, twist and insert the attachment in
direction of the arrow to secure the connection
during use. To disconnect the attachments, twist
and extract it also in direction of the arrow. If an
attachment is twisted in the opposite direction when
being connected or disconnected, the capsule may
become loose.
►Fig.20: 1. Capsule
Cleaning (Suction)
Nozzle
Attach the nozzle to clean off tables, desks, furniture,
etc. The nozzle slips on easily.
►Fig.21: 1. Nozzle
Nozzle + Extension wand (Straight
pipe)
Theextensionwandtsinbetweenthenozzleandthe
cleaner itself. This arrangement is convenient for clean-
ingaoorinastandingposition.
►Fig.22: 1. Cleaner body 2.Extensionwand
3. Nozzle
Corner nozzle
Fit on the corner nozzle for cleaning corners and crev-
ices of a car or furniture.
►Fig.23: 1. Corner nozzle 2. Cleaner body
Corner nozzle +Extension wand
(Straight pipe)
In tight quarters where the cleaner itself cannot squeeze
in, or in high places hard to reach, use this arrangement.
►Fig.24: 1. Corner nozzle 2.Extensionwand
3. Cleaner body
Cleaning without nozzle
You can pick up powder and dust without nozzle.
►Fig.25
