Model No.SC103D CORDLESS THREADED ROD CUTTER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 281019-0 HOOK 1

002 941102-2 FLAT WASHER 5 1

003 961011-9 STOP RING E-4 1

004 911213-7 PAN HEAD SCREW M5X12 1

005 183N49-0 HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263002-9 RUBBER PIN 4 3

󳢢󳢢󳢢󳢢C20 263005-3 RUBBER PIN 6 1

󳢢󳢢󳢢󳢢C30 816U42-8 INDICATION LABEL 1

󳢢󳢢󳢢󳢢C40 816V02-6 CAUTION LABEL 1

󳢢󳢢󳢢󳢢D10 INC. 57

006 620C15-5 LED CIRCUIT 1

007 458373-9 LED HOLDER 1

008 458379-7 SCREW GUIDE 1

009 256267-0 PIN 3 1

010 231403-9 COMPRESSION SPRING 3 1

011 265995-6 TAPPING SCREW 4X18 4

012 140B24-7 FRONT COVER COMPLETE 1

󳢢󳢢󳢢󳢢C10 816U44-4 CAUTION LABEL 1

013 961104-2 RETAINING RING S-24 1

014 347350-5 RETURN PLATE 1

018 144986-9 CAM COMPLETE 1

022 267447-3 FLAT WASHER 14 1

023 211485-7 BALL BEARING 6800LLU 1

024 226168-6 SPUR GEAR 10C 1

025 211485-7 BALL BEARING 6800LLU 1

026 253409-7 FLAT WASHER 17 1

027 254202-2 KEY 4 2

028 265954-0 TAPPING SCREW BIND PT3X8 2

029 226169-4 SPUR GEAR 39 1

030 144990-8 MAGNET HOLDER COMPLETE 1

031 961057-5 RETAINING RING S-17 1

032 144992-4 GEAR COVER COMLPETE 1

033 922212-4

HEX. SOCKET HEAD BOLT

M5X12

034 144989-3 CARRIER COMPLETE 1

035 226166-0 INTERNAL GEAR 48 1

036 226165-2 SPUR GEAR 19 3

037 458374-7 GEAR HOUSING 1

038 911258-5 PAN HEAD SCREW M5X35 2

039 253792-2 FLAT WASHER 26 1

040 144988-5 SPUR GEAR 9 COMPLETE 1

041 226164-4 INTERNAL GEAR 53 1

042 226163-6 SPUR GEAR 21 3

Please order the parts with part number. Print Date 31/3/2020
