Model No.SC103D CORDLESS THREADED ROD CUTTER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

043 144987-7 SPUR GEAR 10B COMPLETE 1

044 226163-6 SPUR GEAR 21 3

045 253410-2 FLAT WASHER 15 1

046 458375-5 GEAR HOUSING COVER 1

047 266490-9 TAPPING SCREW PT 2X6 3

048 652069-6 FLAT HEAD SCREW M3X6 3

049 620C14-7 CONTROLLER 1

050 629448-3 STATOR 1

051 619512-8 ROTOR 1

052 458378-9 F/R CHANGE LEVER 1

053 651367-5 SWITCH C3JW-2CM 1

055 644813-5 TERMINAL 1

056 252173-7 SQUARE NUT 1

057 183N49-0 HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263002-9 RUBBER PIN 4 3

󳢢󳢢󳢢󳢢C20 263005-3 RUBBER PIN 6 1

󳢢󳢢󳢢󳢢C30 816U42-8 INDICATION LABEL 1

󳢢󳢢󳢢󳢢C40 816V02-6 CAUTION LABEL 1

󳢢󳢢󳢢󳢢D10 INC. 5

058 911213-7 PAN HEAD SCREW M5X12 1

060 265995-6 TAPPING SCREW 4X18 10

061 126984-5 CUTTING ARM ASSEMBLY 1

062 856M93-1 SC103D NAME PLATE 1

063 856M99-9 SC103D SERIAL NO. LABEL 1

A01 271445-1 THUMB SCREW M4X10 1

A02 415486-9 DEPTH GAUGE 1

A03 458380-2 BLADE COVER 1

A04 783202-0 HEX. WRENCH 4 1

A05 922202-7

HEX. SOCKET HEAD BOLT

M5X8

A09 199085-2 CUTTER BLADE M8 SET 1

Please order the parts with part number. Print Date 31/3/2020
