Hour meters - TBG series
TBG30.18
Front panel mounting
Mounting aperture 50 x 25mm
Without zero reset
12.01– 1
1. Indicator
Counter capacity: 99 999h
Accuracy of reading: 0.1h
Numeral colour: white, decimal figures red
Numeral height: 4.4mm
Operation indicator: flashing LED
2. Mechanical design
Self-extinguishing plastic housing, IP rating IP54 (on the front)
Class of protection III (up to 48V DC)
Front panel mounting
Shockproof terminal connection according to VBG 4
(terminals IP rating IP20 / AMP plug-type connections 6.3 x 0.8mm)
Initial torque: max. 2.4Nm
Terminal capacity: cylinder head bolt M3x5, DIN 84
3. Input circuit
Supply voltage: 12 to 48V DC
Tolerance: ±10%
Rated consumption: 12V DC approx. 20mW
4. Ambient conditions
Ambient temperature: -10 to +50°C
Storage temperature: -10 to +50°C
Transport temperature: -10 to +50°C
Relative humidity: <90%
5. Accessories
SB-TBX30: Retaining clip for fixing the device in
front panel aperture
Technical data
Subject to alterations and errors
Release 11/01
