*2208335*
2208335 English 21
6 Types of work
WARNING
Damaged power cords are a safety hazard! If the supply cord or extension cord is damaged while work
is in progress, immediately disconnect the device and the cord from the electricity supply. Do not touch the
damaged part of the cord.
▶
Regularly check all supply cords. Replace defective extension cords. Have damaged power cords
replaced by a qualified specialist.
Use of a ground fault circuit interrupter (residual current device, RCD) with a maximum tripping current of
30 mA is recommended.
6.1 General notes on working with the slitting tool
▶ Select the right type of diamond slitting wheel for the material to be cut.
▶ If cutting performance drops, check whether the diamond slitting wheels are badly worn and need to be
replaced or sharpened.
▶ Make vertical cuts from top to bottom by preference.
▶ It is not possible to cut curves.
▶ Guide the slitting tool without turning or tilting it.
6.2 Setting the power tool to its initial position
After installation of the diamond slitting discs or if work has been done on it, the power tool might
not be in its initial position. You must set the power tool to its initial position before the slitting depth
(plunge depth) is set and the power tool is switched on.
1. Make sure that the plunge movement lock button on the front grip is not pressed.
2. Hold the power tool firmly by the front grip.
3. Lift the front of the power tool until the carriage snaps into its initial position with an audible click.
▶ The power tool is now in its initial position.
To make sure that the power tool does not exit from the work surface without you noticing, you
can push the locking switch to the (locked) position. This locks the carriage at the slitting depth
already reached and keeps it locked for as long as the plunge movement lock button is pressed.
6.3 Setting the slitting depth
1. Make sure that the power tool is in its initial position.
2. Turn the slitting-depth adjusting knob to set the desired slitting depth.
The numbers printed on the adjusting knob show slitting depth in millimeters (mm).
6.4 Slitting
1. Make sure that the slitting depth is set correctly. → page 21
WARNING
Risk of accident! If the power tool is not in its initial position when it is switched on, the diamond slitting
wheels can come into contact with the surface underneath the power tool. If this happens it can cause you
to lose control of the power tool.
▶ Before switching on, check that the power tool is in its initial position.
2. Position the power tool on the working surface to be slit.
The cutting line indicator indicates the direction of cut and is in line with the first (left, in the
direction of cut) diamond slitting disc.
For horizontal slits: The spirit level indicates when the power tool is correctly leveled.
3. Flick the centered locking lever to the left or right. Then fully depress the ON/OFF switch and hold it in
this position.
