LG PQRCUCA0 [10/20] Setting the central control address

10 Simple Wired Remote Controller

Note : The remote controller displays 'HL' if central controller has locked the remote controller .

Necessary function before using

Out door

Room Temp

Total on

Central Run

Defrost Preheat

PQRCUCA0

FAN

SPEED

MODE

FAN

SPEED

MODE

Group No.

Indoor Unit No.

If you want to set the address on the display panel,

press both temperature control buttons (▲/▼)same

time for three seconds.

Press the temperature-increasing button to change the

group number. Press the temperature-decreasing

button to change the indoor unit number.

e.g. As shown on the left side panel, it displays 23.

Group No. : 2

Indoor Unit No. : 3

Set the address by pressing both temperature control

buttons again(▲/▼) at the same time for three

seconds.

• If you connect the indoor unit to the central controller, you should set the network

address of the indoor unit so that the central controller could recognize it.

• The center-control address is composed of the group number and the indoor-unit

number.

Setting the Central-Control Address

Please set the address while using the central controller.

You don't need to set address if you don't use central controller.
