LG PQRNC0 [10/22] Junction control system structure
![LG PQRNC0 [10/22] Junction control system structure](/views2/1108212/page10/bga.png)
Installation Manual 9
ENGLISH
Junction Control System Structure
Junction Control System Structure
DRY CONTACT UNIT
LG
AC power
(AC 220V~
234V)
Actuator
Operation signal
(AC power)
A
Remote Controller
Dry Contact Module
Radiator
< Simple Wired remote control System >
< Junction Wired remote control System >
