XLiner / XLiner Combo CONDTROL
XLiner / XLiner Combo CONDTROL
32
33
user manual user manual
EN EN
Operating Modes (see fig. A-D)
The instrument has five operating modes:
The horizontal mode - produces a horizontal laser line.
The vertical mode - produces a vertical line.
The mode of crossing lines - produces a horizontal and vertical line.
The mode of constructing of directions - produces five orthogonal
directions (XLiner Combo only).
The mode of constructing of crossing lines and five orthogonal
directions (XLiner Combo only).
After switching on the instrument is in the horizontal line mode. Press 1 to
change the operating mode.
All five modes can be switched on both with the automatic compensation,
and without the automatic compensation.
Automatic Compensation
Operation with the automatic compensation (see fig. C)
Place the instrument on a horizontal, solid surface or fix it on a tripod.
Move the On/Off D to the left position to work with the automatic
compensation.
The compensator automatically aligns a position within the range of
compensation ±5°. The laser beam starts to blink when the instrument is out
of the range of the automatic compensation, signaling that the instrument
is out of the self-alignment range. In that case place the instrument
horizontally and wait for the end of the automatic compensation.
At pushes and position changes during the work the instrument
automatically does the compensation. Check up a horizontal and vertical
position of the laser lines in relation to the reference points after a repeated
compensation to prevent from errors.
Operation without the automatic compensation (see fig. D)
The On/Off D must be in the right position to work without the automatic
compensation.
This mode allows constructing inclined planes.
At the switched off automatic compensation you can freely hold the
instrument in your hand or place it on a suitable surface. Two laser lines are
not always constructed as orthogonal in the mode of crossing lines.
Accuracy Check
Influence on accuracy
The ambient temperature has the greatest influence. Especially temperature
differences occurring from the ground upward can divert the laser beam.
As thermal fluctuation is largest close to the ground, the instrument,
if possible, should be mounted on a commercially available tripod and
placed in the centre of the working area. Apart from exterior influences,
instrument-specific influences (such as heavy impact or falling down) can
lead to deviations. Therefore, check the accuracy of the instrument each
time before starting your work.
Checking of the horizontal line
For this check, a free measuring distance of 5 meters on a firm surface
between two walls A and B is required.
Mount the instrument onto a tripod or place it on a firm and level surface
close to wall A. Switch on the instrument. Select cross-line operation with
automatic leveling
Direct the laser against the close wall A and allow the instrument to level
in. Mark the centre of the point where the laser lines cross each other on
the wall (point I).
