8
Profactor Armaturen GmbH
Adolf-Kolping-Str. 16, 80336 München, Germany, Telefon: +49 89 21546092
E-mail: info@pf-armaturen.de, Internet: www.profactor.de
5. MATERIALS
Details 1, 20, 21 — CW617N (DIN EN 12165-2011) with chrome-plated surfaces
Details 2, 3, 4, 5, 6, 13 — CW614N (DIN EN 12164-2011) with nickel-plated surfaces
Details 8, 9, 12, 14 — AISI 304 (DIN EN 10088-2005)
Details 10, 11, 15, 16, 17, 18, 19, 22 — EPDM
Details 23, 24 — ABS
1 – body
2 – sleeve
3 – thermostatic chamber
4 – chassis
5 – base
6 – adjusting coupling
7 – thermostatic element
8 – spring of the thermostatic chamber
9 – the thrust rod
10 – cuff
11 – gasket of the thermostatic chamber
12 – damper spring
13 – support plate
14 – spring ring
15, 16, 17, 18, 19 – O-rings
20 – threaded bushing
21 – coupling nut
22 – gasket of the threaded bushing
23 – handle base
24 – flywheel
25 – screw
6. PRINCIPLE OF OPERATION
The desired temperature of the mixed water is set manually by turning the flywheel. Internal
temperature regulation of the mixed water in the valve is carried out automatically thanks to
the heat-sensitive element which, when entering into contact with the mixed water and reacts
by proportional expansion or contraction depending on the set desired value of the
temperature of the mixed water.
With the sudden cessation of the cold water supply, the valve closes the supply of hot water.
This excluses the possibility of the hot water supply to the user without mixing protecting him
from scalding.
EN
