LEO XST 50-160/75, 7,5 кВт, 380В, Qmax. 72,0 m3h, Hmax. 40 m 1466 Тех. данные онлайн

Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

XST50-160/75

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. 50003849

Product Picture Note

Water supply: Water filtration and transportation, the main pipeline

pressurization; Pressurization for high-rise buildings, hotels, etc.

Industry: Flushing and cleaning system, boiler feed water, cooling water

circulation, water treatment system, equipment supporting system.

water treatment: Ultrafiltration system, reverse osmosis system,

distillation system, separator,swimming pool.

Other: Air conditioning system; heating system; agricultural irrigation,fire

fighting system

Nameplate parameters

flow 60 m³/h

head 32.5 m

Efficiency 76 %

speed 2900 rpm

number of stages 1

Technical

Flow range (m³/h) 6-72m3/h

Curve tolerance ISO 9906 Annex A

Maximum lift (m) 40m

Maximum Altitude 1000m

Material

Impeller HT200/06Cr19Ni10

Pump inlet HT200

Pump shaft

Fan cover 08F

O-ring NBR

Rear end cover ZL102

Connector HT200

Fan PP

Cover box ABS

Supporting foot HT200

Guard plate

Working conditions

Medium temperature (°C) -10°C+85°C

Max. ambient temperature (°C) +40°C

Pumped medium

Liquid without solid particles and long fiberslow viscositynon-combustiblenon-corrosion liquid or other

Critical cavitation margin(m) 2.5m

Working pressure 12bar

Installation

Structure Type Non-standard motor (Coaxial)

Connection method Flange connection / thread-connection

Inlet diameter (mm) DN65

Outlet diameter (mm) DN50

Motor

Motor phase Three phase

-1-
