LEO LPP 80-19-5.5/4, 5,5 кВт, 380В, Qmax. 80,0 m3h, Hmax. 21,5 m 1895 Тех. данные онлайн

LEO LPP 80-19-5.5/4, 5,5 кВт, 380В, Qmax. 80,0 m3h, Hmax. 21,5 m 1895 Тех. данные онлайн

Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

LPP80-19-5.5/4

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. LPP80-19-5.5/4

Product Picture Note

:

CFD

Nameplate parameters

flow 68 m³/h

head 19 m

speed 1480 rpm

number of stages 1

Technical

Curve tolerance IS09906 AnnexA

Maximum lift (m) 21.5

Minimum usage flow (m³/ h) 7

Maximum use flow (m³/ h) 80

Material

Impeller HT200

Pump inlet HT200

Pump shaft AISI304

Mechanical seal SiC/C

O-ring NBR

Working conditions

Max. ambient temperature (°C) 40

Max. liquid temperature (°C) 90

Pumped medium

Working pressure 16bar

Installation

Inlet & Outlet Diameter DN80

Connection standard DIN

Motor

Motor phase Three phase

Protection class IP55

Motor poles 4

Insulation class F

Motor power (KW) 5.5KW

Frequency 50

Rated voltage (V) 380

Rated current (A) 11.2365338223874

Efficiency class IE3

Power factor 0.83

-1-
