Recorders I HD-TVI I Standalone

HDVR

I/O Interface

Audio Outputs:

1-ch, RCA (2.0Vp-p, 1KΩ)

Harddisk bay:

1 x SATA

Network Interface:

1x 10, 100 Base T, TX (RJ-45)

Serial Interface(s):

Front panel: 1 × USB 2.0, Rear panel: 1 × USB 2.0, 1 x RS485

CVBS Output:

1-ch, BNC (1.0 Vp-p, 75 Ω) , resolution: PAL: 704 × 576, NTSC: 704 × 480

VGA Output:

1920×1080, 60Hz, 1280×1024, 60Hz, 1280×720, 60Hz, 1024×768, 60Hz

Intelligent Functions

Intelligent Video Analytics:

Facial detection (2-ch max.) and human/vehicle analysis (2-ch max.). These functions cannot be

enabled at the same time. Enable one function will make the other one unavailable.

Face Detection:

Human face capture for 1 Channel HD analog camera

Motion Detection:

On, Off, Area Setting

Event Action:

Pop-Up, Relay, E-Mail, FTP, Network, Buzzer, PTZ Preset

Event Source:

Motion, Alarm, Video Loss, System

Approvals

ONVIF compliant:

Profile S, Profile G

Regulation:

CE, EAC, FCC, RoHS Compliant

Environmental

Operating Temperature:

-10 °C ~ +55 °C (+14 °F ~ + 131 °F)

Operating Humidity:

10% ~ 90%, non-condensing

Electrical

Supply Voltage:

12 VDC, Power Adapter 100 ~ 240 VAC 50, 60Hz included

Power Consumption:

≤ 18 W without harddisk

Mechanical

Dimensions:

315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)

Weight:

1160 g (2.6 lb)

Dimensions:

grundig-security.com

EAN CODE: 4260573060535

Item Code: GD-RT-AC3004N

®Abetechs GmbH (Grundig Security), Düsseldorf, Germany

Page 3 of 4

11.12.2020 I Data subject to change without any notice I
