Sven 315 [15/19] Usb multimedia speaker system

2. PACKAGE CONTENTS

• Speakers — 2 pcs

• Operation manual — 1 pc

• Warranty card — 1 pc

3. SAFETY PRECAUTIONS

• Do not open the MSS and do not perform repairs by yourself. Service and repairs should be per-

formed only by qualiﬁed specialists at authorized service centers. The list of authorized service

centers is on www.sven.ﬁ.

• Do not allow the circuit of wires (including the grounded ones) between the speakers, on the

power ampliﬁer or the ground, for it causes damage to the power ampliﬁer output stage.

• Make sure that foreign objects do not get inside the holes of the MSS.

• Protect the MSS from high humidity, water and dust.

• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose it

to direct sunlight.

• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

• If the MSS does not operate, unplug it and address your dealer.

4. TECHNICAL DESCRIPTION

Sven 315 USB Multimedia Speaker System 2.0 (MSS) is designed to play music and sound games,

movies etc. MSS has built-in bridge ampliﬁer, acoustic and signal cable due to which it can be

connected to virtually any audio source (CD/DVD-players, TV, PC, etc.). MSS is connected to

power supply via USB-port of a PC, laptop or 5V DC power supply with a cable USB. The speaker

which has audio and control panel is named active one.

MSS special features

• U.S.S. (Ultra Sound System) – built-in bridge ampliﬁer ensures output power 4 times higher than

that of AB class ampliﬁers

• Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound

sources

• Power supply via USB-port of a PC, laptop or 5V DC power supply

• Volume control

• Audio sources stereo audio input

• Plastic speakers cabinets

Rear panel

a VOLUME: volume control knob

b OUTPUT: passive speaker jack

c INPUT: signal cable mini-jack Ø 3,5 mm

d USB: USB cable

ENG

2.0 USB Multimedia

Speaker System
