EN 7

Figure D

233mm

Hit screw

Machine

Figure E

Leakage protection switch

Power cord

Flow valve

Hot water outlet

Cooling water inlet

Angle valve

Gasket Gasket

Gasket

● Fixed water heater：Lift the water heater and insert the installation bracket into the installation holes on its back.

Then, use cross countersunk self-tapping screws to securely fasten and �x it. Only after ensuring the installation is �rm,

you can release your grip to prevent it from falling.

● Accessories installation: Refer to (Figure E) for connections.

CAUTION

● A sealing ring must be used at the pipe joint, and a valve must be installed at the water inlet pipe.

● The inlet pipe has a built �lter screen, pay attention to check when connecting the pipe to prevent loose and leak

installation.
